## Abstract

Holographic speckle is a major impediment for the emerging applications of multiphoton holographic projection in biomedical imaging, photo-stimulation and micromachining. Time averaging of multiple shifted versions of a single hologram (“shift-averaging”) is a computationally-efficient method that was recently shown to deterministically eliminate holographic speckle in single-photon applications. Here, we extend these results and show, computationally and experimentally, that in two-photon holographic excitation shift-averaging also reduces holographic speckle better than “random” averaging of multiple calculated holograms.

©2011 Optical Society of America

## 1. Introduction

Computer Generated Holographic (CGH) projection using Liquid-Crystal Spatial Light Modulators (LC-SLMs) is a powerful strategy for generating intense multi-focal dynamical light distributions in two or three dimensions, which has recently found applications in a variety of technological fields, including micro-fabrication [1], optical trapping [2] and neural stimulation [3,4]. SLMs have the added advantage of being dynamic; rapidly-changing sequences of CGHs may be displayed, with rates of up to several kHz.

Holographic speckle is a major source of image distortion associated with the projection of patterns consisting of contiguous shapes (rather than sparse diffraction-limited spots), as required by certain applications, such as microfabrication and neural stimulation [3,4]. In the reconstruction plane, a rectangular lattice of sinc-shaped Point Spread Functions (PSFs) is observed. Ideally, the complex amplitude of each such PSF should be user-defined. However, most phase retrieval algorithms, such as the Gerchberg-Saxton algorithm [5], only present restrictions on the magnitude of the field in the SLM and the reconstruction plane, with the phases remaining as free parameters. In practice, this results in random interferences between the contiguous PSFs leading to speckled light patterns. A common theme for many of the methods developed to solve or circumvent this problem is time-averaging [6]. For example, using a rotating diffuser, it is possible to physically average many instances of the resultant pattern, each with a different pseudo-random phase function, thus reducing speckle [7]. This, however, requires another optical element in the path, which could prove costly in terms of image quality. Another solution is to calculate N different holograms for the same desired pattern and display them in rapid succession [8], causing the speckle contrast to be reduced by a factor of *N*^{1/2} [9]. Of course, this method is marred by significantly heavier computational demands per pattern.

Recently, we introduced shift-averaging [10], a new method for speckle elimination in which a *single hologram* is calculated and undergoes several periodic two-dimensional cyclic shifts, which are sequentially displayed (as in regular time averaging). We found that cyclic shifts can be chosen that ensure the *deterministic elimination* of the mathematical cross-terms describing the interference between each pair of PSFs in the *time-averaged intensity* of the reconstruction plane pattern. In practice, this deterministic elimination (instead of random averaging in conventional time averaging) yields a major reduction of the intensity speckle contrast even when averaging a small number of holograms. Combined with the associated major reduction in computational burden, this has lead to the rapid adoption of this technique in applications ranging from holographic televisions [11], to one-photon neural stimulation [4] to laser marking [12] (which is likely to increase as faster SLMs become increasingly available).

One of the most exciting recent developments in holographic projection is the emergence of major applications where nonlinear optical excitation is used to achieve tight axial sectioning. These emerging applications include two-photon holographic fluorescence microscopy [13,14], photo-polymerization [1,15] and activation of light-gated ion channels for stimulating neurons in the brain [16]. The problem of holographic speckle is even more critical in nonlinear projection than it is in one-photon projection: partially because speckle contrast is much stronger in <*I ^{2}*> than it is in <

*I*> [7] and partially because the use of image patches is more crucial in nonlinear excitation where high numerical aperture objectives are used and individual diffraction limited spots have submicron dimensions that are too small to excite “large” targets like cells [16,17]. In certain applications of two-photon CGH, holographic speckle has arguably emerged as the absolute limiting factor, and has led researchers to explore “smoother” alternatives like generalized phase contrast [16]. A simple speckle-reduction solution like shift-averaging, could potentially be useful in tackling this challenge, however, shift-averaging deterministically eliminates speckle-forming cross-terms only in the time-averaged light intensity. In contrast, the expression for the time-averaged

*squared-*intensity, which determines the integrated efficacy of two-photon phenomena, has a significantly more complex mathematical structure with a dramatically higher number of cross-terms, and there is no a priori reason to assume that it would become speckle-free under shift averaging.

In this paper, we study the performance of shift-averaging for reducing speckle noise in the squared intensity pattern. In section 2, the mathematical ground for one-photon shift-averaging is first laid, followed by an analysis of the effect of shift-averaging on speckle noise in the two-photon case, which is then demonstrated by a simulation in section 3. Section 4 presents the experimental results obtained using a two-photon holographic projection system, which are discussed, along with the other findings, in section 5.

## 2. Mathematical analysis

#### 2.1 One-photon case

The following mathematical derivations directly follow [10]. For simplicity, we assume a square SLM containing *M* × *M* pixels and define the phase-only hologram as a 2D matrix:

A plane wave interacting with the SLM would have its amplitude transmitted according to

*f*values are periodic in

_{kl}*k*and

*l*, with periodicity

*M*. The series of functions

*S*are assumed to include all the mathematical information describing the wave's propagation through optical apertures, such as that of the SLM or that of any lens in the system. It also includes a slowly decaying sinc envelope brought about by the finite size of the SLM's pixel. For example, if the initial wave overfills the SLM's aperture, but is not truncated by any lenses that follow,

_{kl}*S*would becomeif, on the other hand, the wave were to overfill a lens,

_{kl}*S*would include a Bessel term. However, the exact constituents of

_{kl}*S*are implicit in the rest of the analysis, provided that it maintains the form of a narrow Point Spread Function (PSF).

_{kl}It follows from Eqs. (4) and (5) that the reconstruction plane can be thought of as an infinite 2D lattice of such PSFs, each with its own phase introduced by the *f*_{kl} values. In the case of Eq. (5), each such PSF is equal to zero in all lattice points save the one corresponding to it, rendering the reconstruction on the lattice points exact and interference-free. However, in every other point in the reconstruction plane, an interference occurs between the contributions of an infinite number of PSFs from all lattice points; assuming the desired reconstructed shape is that of a contiguous patch, the randomness of the phase values of *f*_{kl} causes rapid spatial fluctuations in the electrical field, which is manifested as speckle noise.

Because the PSFs are spatially narrow functions, it is possible to approximate the electrical field's value at a specific point $(u,v)$, by taking into account the contributions of the lattice points in its immediate neighborhood only, as shown in Fig. 1(a)
. Assuming a square neighborhood consisting of *c* by *c* such PSFs, the electrical field in each point can be approximated by

*k*and

*l*are as shown in Fig. 1(a). The square modulus of the approximation in Eq. (6) describes the intensity at a point $(u,v)$:

Assuming *N* holograms, theoretically resulting in the same reconstruction pattern but each accompanied with its own speckle patterns, and assuming they are displayed sequentially and periodically on the SLM at a fixed rate, the average intensity recorded over one period of display is given simply by averaging several instances of Eq. (7):

*a*refers to the a -th hologram. Using a one-photon system, a perfect time-averaging-based speckle-elimination method would use

*N*holograms that would eliminate all cross-terms, that is, the terms which include more than a single lattice points. Formulated mathematically, this requirement is akin to writing

In a previous paper [10], we have shown that by calculating only a *single* hologram and shifting its contents cyclically and periodically in a specific manner, the speckle is eliminated completely, in theory, and almost completely, in practice. Cyclic shifting, illustrated in Fig. 1(b), introduces a linear phase addition:

#### 2.2 Two-photon case

The previous subsection's results are confined to phenomena which are proportional to the field's intensity. However, in two-photon phenomena, which are proportional to the square of the intensity, using a time-averaging approach will yield an effect proportional to *the average of the squared intensities*, which is different from *a square of the averaged intensity* (a square of the expression in (8)). Therefore, the specific choice of shifts defined by (12) does not guarantee a speckle-free reconstruction in the two-photon case, and its effect requires a different analysis that will be presented in this subsection.

The squared intensity of a single holographic reconstruction is given by

*c*, indicating a much more complex speckle pattern. Again, upon time-averaging, Eq. (14) becomes

^{8}The ideal averaging method would eliminate all *c ^{8}* terms except those for which all the first indices from each of the four pair presented above coincide, as well as all of the second indices. In other words, ideal averaging would eliminate all cross-terms, leaving us with

*c*terms, each corresponding to a single lattice point. Mathematically put, ideally

^{2}However, trying to apply shift-averaging with the above-mentioned shifts in this case results in

It has been shown, then, that using the shift-averaging method that worked well for the intensity case, performs differently for the case of the squared intensity: rather than being left with two four-dimensional Kronecker's deltas, as is ideal, we are instead left with two two-dimensional ones. Effectively, this means that not all the cross-terms are averaged out: instead of *c*^{8} terms, out of which one would ideally remain with *c ^{2}*, here we are left with all the crossterms satisfying

The number of pairs $\left\{\left(k,g\right)|1\le k,g\le c;\text{\hspace{0.17em}}\left(k,g\right)\in {\mathbb{N}}^{2}\right\}$ with a certain sum *k+g=w*, $2\le w\le 2c$, is $c-\left|c+1-w\right|=\{\begin{array}{cc}w-1& w\le c+1\\ c+1-(w-c)& w>c+1\end{array}$. Thus, the number of quadruplets satisfying *each* equation is: $\sum _{w=2}^{2c}{\left(c-\left|c+1-w\right|\right)}^{2}}={1}^{2}+{2}^{2}+\dots +{c}^{2}+{\left(c-1\right)}^{2}\dots +{2}^{2}+{1}^{2}=$ $=\left(2{c}^{3}+c\right)/3$, of which *c* terms are desirable diagonal terms. Hence, the overall proportion of unwanted terms which remain after shift averaging is

*c*. Figure 2 shows a graphic representation of this term as a function of

^{−2}*c*; even at a low

*c =*4 (i.e., using 16 holograms) the fraction of remaining cross-terms is roughly 3%, indicating a major improvement potential in the expected SNR over the case of random averaging of

*c*samples.

^{2}So, while shift-averaging cannot eliminate all existing cross-terms in the quantity of relevance for two-photon phenomena (the field's squared intensity), it does average out the vast majority of these cross-terms.

## 3. Simulation

The previous result provides an initial indication that shift averaging may considerably ameliorate two-photon holographic speckle phenomena. To further evaluate this effect we calculated and shift-averaged holograms producing two different patterns (a square patch and multiple cross-like patches, see Fig. 3
). For the different projected patterns we evaluated the speckle contrast, defined as the ratio between the standard deviation and the mean value of the signal of interest *G* (for example, one- or two-photon fluorescence), across the pattern’s area:

As can be seen in Fig. 3(a), two-photon holographic speckle is much higher than in the one-photon case: without any averaging, the speckle contrast is about twice as large. However, as little as 4x4 averaging (16 holograms) significantly improves the two-photon holographic speckle, reducing it by a factor of 4 to 6. Moreover, compared to regular time-averaging methods, not only is two-photon shift averaging beneficial in its significantly lower computational demands, but also in terms of the better speckle amelioration achieved using the same number of holograms, as shown in Fig. 3(b). This improvement appears particularly strong in the case of the pattern consisting of a number of patches - a difference that probably has to do with the smaller size of the contiguous patches. A point in a bigger patch is affected by more neighbors, requiring a larger c-by-c neighborhood to achieve the same speckle reduction effect obtained with a smaller patch.

## 4. Experimental results

The performance of two-photon shift-averaging was then experimentally verified using a multiphoton SLM-based holographic projection system portrayed in Fig. 4 . An ultrafast Titanium-Sapphire laser (MaiTai WB, Spectra-Physics), emitting 180-fs 800nm laser pulses was expanded and its polarization matched to that of the SLM (XY Phase, Boulder Nonlinear Systems), before having its width modified by another telescope (L1 and L2) to match the objective lens’s back aperture (60x, Apo NIR; Nikon). A CCD (GC1380H, Prosilica) was used to image the reconstruction plane.

Figure 5 shows an example of shift averaging performed in the optical system portrayed above. A hologram corresponding to a pattern of several circular patches was calculated and displayed on the SLM. Upon projection onto a thin slide of fluorescein, the projected pattern gives rise to a very noisy two-photon fluorescence image. When applying 4x4 shift averaging, however, the high-frequency noise is mostly gone and the signal appears to be much smoother, accompanied by a speckle contrast reduction of about one order of magnitude.

## 5. Discussion

In this work, we have analyzed the performance of the shift-averaging method in the case of two-photon projection, where the observed excitation phenomenon is proportional to the squared intensity. We have shown analytically that shift-averaging eliminates many of the unwanted speckle terms in the average squared intensity pattern, although some unwanted terms remain. Our simulations show that shift-averaging equals or outperforms regular averaging in terms of holographic speckle contrast. This is achieved with the calculation of a single hologram per projected pattern, saving computation time compared to the multiple- hologram averaging approach. The effectiveness of shift-averaging for ameliorating speckle was also experimentally demonstrated by imaging two-photon fluorescence excited by holographic patterns.

The applicability of two-photon shift averaging has some important limitations. One limitation of this approach is that it relies on the hologram being shift invariant except for the induced phase modulations in the output light pattern, and is therefore applicable only in light projection of 2D light patterns. This, however covers most of the recent applications of optically sectioned holographic nonlinear excitation [13,16], where the 3rd dimension is obtained by moving the objective.

Secondly, as the SLM used in this work could operate at a refresh rate of 100Hz at most, shift averaging using 16 holograms (4x4) reduces the maximal refresh rate to roughly 6Hz. Generally, time averaging methods are more suitable for fast SLMs, such as the binary, ferroelectric (rather than nematic) SLMs [10], which could operate at refresh rates of several kHz. Unfortunately, ferroelectric SLMs have a relatively low diffraction efficiency, and the practical implementation of rapid time-averaging in holographic two photon projection may await the development of projection tools that combine the benefits of high diffraction efficiency and fast refresh rates [19].
