JET application (download release package with sample code - release_jet_mcs_v1.zip) renders bar chart with data retrieved from MCS endpoint returning information about employees:
Once data is retrieved, I can see invocation statistics logged and reported in MCS dashboard. Calls are executed successfully:
To call MCS service from Oracle JET, we need to pass to extra headers - Authorization and Oracle-Mobile-Backend-ID. Values for both headers can be obtained from MCS dashboard. Go to Mobile Backend and navigate to Settings section. You will find required info under HTTP Basic section:
To bypass CORS issue, you can specify Security_AllowOrigin property in MCS (you need to be admin for this). Read more about it in MCS Developer Guide - Environment Policies and Their Values. Download property file to your local environment, change it and upload back:
For test purposes, I have specified Security_AllowOrigin=allow:
Oracle JET application JS module is pointing to REST URL handled by MCS:
Fetch operation is configured to pass two headers specific to MCS - this will allow to complete REST request and get response:
NetBeans tool Network Monitor displays request headers (both MCS headers are included):
If request is successful, you should see data returned in the response:
If we look at the layer communication (Figure 2.2 from VPN Illustrated) we see the different layers of the OSI layer represented
Today we are going to be talking about the Transport Layer or Layer 3. An example of an application would be a web browser communicating to a web server. The web browser would connect to the ip address of the web server and make an http request for a file. The http request is an example of an application layer request. At the TCP layer we have to define the handshake mechanism to request and receive the file as well as the port used for the request. Ports are a new concept where we not only talk to the ip address of a server but we specifically talk to it through a specific protocol that the server has a listener ready and available for requests. In our web browser example we read clear text web pages on port 80 typically and secure web pages on port 443. The secure web page not only can accept a file download request but does it without anyone else on the network knowing what is being asked because the communication between the web browser and web server is encrypted and encoded to prevent anyone from snooping traffic that is being exchanged. This is needed if you want to transmit secure information like credit card numbers, social security numbers, or any other financial related keys that assist in doing commerce across the internet.
- ifconfig on Linux allow you to control the status of an internet connection
- ipconfig on Windows is a similar tool
We just mentioned a new term here, a firewall. A firewall is a program that runs on a server and either allows traffic through or disables traffic on a specific port. For example, if we want to allow anyone on our subnet access to our web page, we open up port 80 to the same subnet that we are on. If our corporate subnet consists of more than just one subnet we might want to define an ip address range that we want to accept requests from. A firewall takes these connection requests at the TCP layer and opens up the TCP header, inspects it looking at the source and destination address as well as the port that is used for communications. If the port is open and allowing traffic from a subnet or ip address range, the request is then passed to the web server software. If the port is open but the traffic is coming outside of the ip address range, the request is dropped and an error is returned or the tcp/ip packet is dropped based on our firewall rules. The same is true for all ports that attach to compute engines on the internet. By default most cloud vendors open up port 22 which is the ssh port that allows you to connect to a command line on a Linux or Unix server. Microsoft Azure typically opens up port 3389 which is the remote desktop connection port. This allows you to connect to a Windows desktop using the RDP application on Windows desktops. It is typically a good idea to restrict the ip address that you can connect to your compute cloud server from an ip address rather than from any address.
We could consider a router to be an implementation of a firewall. A router between your subnet and the corporate network would be a wide open firewall. It might not pass UDP headers and most likely does not pass multicast broadcasts. It will not typically pass non routable addresses that we talked about yesterday. If we have a 192.168.1.xxx address we typically don't route this outside of our local network by definition since these are local private addresses. A router can block specific addresses and ports by design and act like a firewall. For example, Oracle does not allow ftp access from inside of the corporate network to outside servers. The ftp protocol transmits user names and passwords in the clear which means that anyone using tools like tcpdump, ettercap, and ethereal can capture and display the passwords. There are more secure programs like sftp that performs the same function but not only encrypts the username and password but each data byte transmitted to and from the server.
Many routers like wifi routers that most people have in their homes allow for network address translation (NAT) so that you are not presenting the 192.168.1.xxx address to the public internet but the address of your router/modem that connects you to the internet. Your desktop computer is at address 192.168.1.100, for example, but resolves to 126.96.36.199 with your internet provider. When you connect to port 80 at address 188.8.131.52 which correlates to http://cnn.com you connect to port 80 with a TCP/IP header source address of 184.108.40.206 and a destination address of 220.127.116.11. When your router gets a response back it knows that it needs to forward the response to 192.168.1.100 because you connected with a header value that said you were using a NAT connection. The router bridges this information back to you so that you don't need to consume more ip addresses on the internet for each device that you connect with from your home. The router/modem translates these requests using NAT, Bridge links, or actual IP addresses if you configure your back end server to request a direct mapping.
If we put all of this together along with the route command on Windows or Linux, we can define a default router that will take our IP packets and forward them to the right path. It might take a hop or two to get us to our eventual destination but we should be able to use something like Figure 2.9 from VPN Illustrated to represent out access to the Internet and use tool like traceroute to look at the hops and hop cost for us to get to the different cloud servers.
Note in this diagram if we are on Host 4 we set our default router to be router 2. We then trust that router 2 will know how to get to router 1 and router 1 will take us to our desire to look at cnn.com or whatever web site we are trying to connect to. All cloud vendors provide a default router configuration. All cloud vendors will give you a way of connecting to the internet. All cloud vendors will give you a way of configuring a firewall and subnet definitions. We might want to create a database server that does not have an internet connection and we need to connect to our application server through ssh then ssh into our database server through a private network. We might not have a public internet connection for our database but hide it in a subnet to keep it secure. In our routing map from VPN Illustrated we might want to put our database on host 4 and disable any connection to the internet. We might only want to allow traffic from the 200.10.4.xxx network to connect to the database. We might want to allow ssh, port 80, and port 443 connection to host 1 and allow only host 1 to connect ssh to host 4. All could vendors allow you to do this and configure virtual networks, subnets, firewalls, and netmasks.
We recommend that you get an IaaS account on AWS, Azure, and Oracle IaaS and play. See what works. See what you can configure from the command line. See what requires console configuration and your options when you provision a new operating system. See what you can automate with Orchestration scripts or python scripts or chef/puppet configurations. Automation is the key to a successful deployment of a service. If something breaks it is important to be able to automate restarting, sizing up, and sizing down services and this begins at the compute layer. It is also important to see if you can find a language or platform that allows you to change from one cloud vendor to another. Vendor lock in at this level can cause you to stick with a vendor despite price increases. Going with something like bitnami allows you to select which vendor is cheapest, has the best network speeds and options, has the fastest chips and servers, as well as the best SLAs and uptime history.
We didn't dive much into UDP. The key difference between TCP and UDP is the acknowledgement process when a packet is sent. TCP is a stateful transmission. When a web request is asked for by a browser the client computer sends a TCP/IP packet. The web server responds that it got the request and sends an acknowledgement packet that it received the request. The web server then takes the file that was requested, typically something like index.html, and sends it back in another TCP/IP packet. The web browser responds that it received the file with an acknowledgement packet. This is done because at times the Internet gets busy and there is a chance for collision of packets and the packet might never get delivered to the destination address. If this happens and the sender does not receive an acknowledgement it resends the request again. With a UDP packet the handshake does not happen. The sender sends out a packet and assumes that it was received. If there was a collision and the packet got dropped it is never retransmitted. Applications like Internet Radio and Skype use this type of protocol because you don't need a retransmission of audio signals if the time to listen to it has passed. The packet is dropped and the audio is skipped and picked up at the next packet transmitted. Most cloud vendors support UDP routing and transmission. This is optional and typically a firewall configuration. It might or might not make sense for a database to send and receive using UDP so it might not be an option when you get the Platform as a Service. Most Infrastructure as a Service vendors provide configuration tools to allow or block UDP.
In summary, we have covered basic addressing, routine, firewalls, and touched briefly on the TCP and UDP headers. We don't really need to get into the depths of TCP and how packets are transmitted, how congestion is handled, and how collisions are compensated for. In a cloud vendor you typically need to ask if the network is oversubscribed or bandwidth limited. You also need to ask if you have configuration limitations and restrictions on what you can and can not transmit. One of the risks to an unlimited network is noisy neighbor and getting congestion from another virtual machine that you are provisioned with. On the other hand if your network is oversubscribed you have to be bandwidth limited and accessing your storage can limit your application speed. Our advice is know your application, know if you are network limited, and know the security model and network configuration that you want ahead of time. Every cloud vendor differentiates their services but few offer service level agreements on bandwidth and compute resources. Read the fine details and play with all options.
