Retro Day - Workload Management in WebLogic Server

Thu, 2014-09-11 21:38
Quite recently, I stumbled across this older but still very relevant whitepaper on the workload management capabilities of  WebLogic Server.  Written by one of the key engineers at the time, who later went on to become an architectect, it explains the workings of the new work load management feature introduced into WebLogic Server at the time and covers the concepts of work-manager configuration and effect, work scheduling and prioritization, overload protection and  more.

This is well worth a read if you are ever looking for good information on the work load management feature of WebLogic Server:

http://www.oracle.com/technetwork/articles/entarch/workload-management4-101578.html

JSON Parsing is Cake with WebLogic Server 12.1.3

Thu, 2014-07-31 18:46
Another feature of WebLogic Server 12.1.3 that developers will find really useful is the inclusion of an implementation of JSR-353 Java API for JSON Processing.

See Chapter 10 Java API for JSON Processing in the Developing Applications for Oracle WebLogic Server book @ http://docs.oracle.com/middleware/1213/wls/WLPRG/java-api-for-json-proc.htm#WLPRG1055

The original JSR submission for this API provides a good description of what it sets out to do.

JSR 353: JavaTM API for JSON Processing

This new API, working from the foundations provided by earlier implementations such as Jackson, Jettison and Google JSon, provides a standard API for working with JSON from Java. The goals and objectives of the API are described in the specification request as:
 JSON(JavaScript Object Notation) is a lightweight data-interchange format.

Many popular web services use JSON format for invoking and returning the data.

Currently Java applications use different implementation libraries to produce/consume JSON from the web services. Hence, there is a need to standardize a Java API for JSON so that applications that use JSON need not bundle the implementation libraries but use the API. Applications will be smaller in size and portable.

The goal of this specification is to develop such APIs to:
  • Produce and consume JSON text in a streaming fashion(similar to StAX API for XML)
  • Build a Java object model for JSON text using API classes(similar to DOM API for XML)
WebLogic Server 12.1.3 includes a module which contains the API/implementation of this relatively lightweight but important API, enabling developers and applications to more easily work with JSON in a portable, standard manner.

 Unlike JAX-RS 2.0 and JPA 2, both of which have pre-existing specification versions that need to be supported by default, there are no additional steps required for applications to use this API with WebLogic Server 12.1.3.  It's simply included as a default module of the server and available for any application to make use of.
The API and implementation is located in this jar file in a WebLogic Server 12.1.3 installation:

$ORACLE_HOME/wlserver/modules/javax.json_1.0.0.0_1-0.jar

In the my previous post, Using the JAX-RS 2.0 Client API with WebLogic Server 12.1.3
I have a short example of using the API to parse an JAX-RS supplied InputStream to marshall a JSON payload into a Java object.


...
GeoIp g = new GeoIp();
JsonParser parser = Json.createParser(entityStream);
while (parser.hasNext()) {
switch (parser.next()) {
case KEY_NAME:
String key = parser.getString();
parser.next();
switch (key) {
case "ip":
g.setIpAddress(parser.getString());
break;
case "country_name":
g.setCountryName(parser.getString());
break;
case "latitude":
g.setLatitude(parser.getString());
break;
case "longitude":
g.setLongitude(parser.getString());
break;
case "region_name":
g.setRegionName(parser.getString());
break;
case "city":
g.setCity(parser.getString());
break;
case "zipcode":
g.setZipCode(parser.getString());
break;
default:
break;
}
break;
default:
break;
}
}
...

The Java EE 7 tutorial has a section showing how to use the new javax.json API which is well worth having a look at if working with JSON is your thing.

http://docs.oracle.com/javaee/7/tutorial/doc/jsonp.htm

Arun Gupta also has a good hands-on lab under development for Java EE 7 that uses the JSON API to read and write JSON into Java objects that represent a movie database.   His examples collaborate with JAX-RS to issue both GET and POST calls to read and update data using JSON payload.

https://github.com/javaee-samples/javaee7-samples



Developing with JAX-RS 2.0 for WebLogic Server 12.1.3

Thu, 2014-07-31 00:47
In an earlier post on the topic of Using JAX-RS 2.0 with WebLogic Server 12.1.3, I described that we've utilized the shared-library model to distribute and enable it.

This approach exposes the JAX-RS 2.0 API and enlists the Jersey 2.x implementation on the target server, allowing applications to make use of it as when they are deployed through a library reference in a weblogic deployment descriptor.

The one resulting consideration here from a development perspective is that since this API is not part of the javaee-api-6.jar nor is it a default API of the server, it's not available in the usual development API libraries that WebLogic provides.

For instance the $ORACLE_HOME/wlserver/server/lib/api.jar doesn't contain a reference to the JAX-RS 2.0 API, nor do the set of maven artifacts we produce and push to a repository via the oracle-maven-sync plugin contain the javax.ws.rs-api-2.0.jar library.

To develop an application using JAX-RS 2.0 to deploy to WebLogic Server 12.1.3, the javax.ws.rs-api-2.0.jar needs to be sourced and added to the development classpath.

Using maven, this is very simple to do by adding an additional dependency for the javax.ws.rs:javax.ws.rs-api:2.0 artifact that is hosted in public maven repositories:

    <dependency>
<groupid>javax.ws.rs</groupid>
<artifactid>javax.ws.rs-api</artifactid>
<version>2.0</version>
<scope>provided</scope>
</dependency>

Note here that the scope is set to provided since the library will be realized at runtime through jax-rs-2.0.war shared-library that it deployed to the target server and referenced by the application. It doesn't need to be packaged with the application to deploy to WebLogic Server 12.1.3.

For other build systems using automated dependency management such as Gradle or Ant/Ivy, the same sort of approach can be used.

For Ant based build systems, the usual approach of obtaining the necessary API libraries and adding them to the development CLASSPATH will work. Be mindful that there is no need to bundle the jax.ws.rs-ap-2.0.jar in the application itself as it will be available from the server when correctly deployed and referenced in the weblogic deployment descriptor.

Using Eclipse (OEPE) to Develop Applications using WebSocket and JSON Processing API with WebLogic Server 12.1.3

Wed, 2014-07-30 01:11
Following from my last posting, I thought I'd also show how Eclipse (OEPE) makes the new Java EE 7 APIs available from Oracle WebLogic Server 12.1.3.

The first step was downloading and installing the Oracle Enterprise Pack for Eclipse (OEPE) distribution from OTN.

http://www.oracle.com/technetwork/developer-tools/eclipse/downloads/index.html

Firing up Eclipse, the next step is to add a new Server type for Oracle WebLogic Server 12.1.3, pointing at a local installation.






With that done, I then created a new Dynamic Web Project that was directed to work against the new WebLogic Server type I'd created.  Looking at the various properties for the project, you can see that the WebSocket 1.0 and JSON Programming 1.0 libraries are automatically picked up and added to the Java Build Path of the application, by virtue of being referenced as part of the WebLogic System Library.



Into this project, I then copied over the Java source and HTML page from my existing Maven project, which compiled and built successfully.

For new applications using these APIs, Eclipse will detect the use of the javax.websocket API and annotations, the javax.json API calls and so forth and present you with a dialog asking you if you want to import the package to the class to resolve the project issues.



 With the application now ready, selecting the Run As > Run on Server menu option launches WebLogic Server, deploys the application and opens an embedded browser instance to access the welcome page of the application.


And there's the test application built in Eclipse using the WebSocket and JSON Processing APIs running against WebLogic Server 12.1.3.


Developing with the WebSocket and JSON Processing API with WebLogic Server 12.1.3 and Maven

Tue, 2014-07-29 19:21
Oracle WebLogic Server 12.1.3 provides full support for Java EE 6 and also adds support for a select set of APIs from Java EE 7.

The additional APIs are:
  • JSR 356 - Java API for WebSocket 1.0
  • JSR 353 - Java API for JSON Processing
  • JSR 339 - Java API for RESTful Web Services 2.0
  • JSR 338 - Java Persistence API 2.1
See the "What's New in 12.1.3 Guide" at http://docs.oracle.com/middleware/1213/wls/NOTES/index.html#A1011612131 for more general information.

At runtime, the WebSocket and JSON Processing APIs are available as defaults and don't require any form of post installation task to be performed to enable their use by deployed applications.

On the other hand, the JPA and JAX-RS APIs require a step to enable them to be used by deployed applications.

Developing with the WebSocket and JSON Processing APIs using Maven To create applications with these APIs for use with Oracle WebLogic Server 12.1.3, the API needs to be made available to the development environment.  Typically when developing Java EE 6 applications, the javax:javaee-web-api artifact is used from the following dependency:
<dependency>
<groupId>javax</groupId>
<artifactId>javaee-web-api</artifactId>
<version>6.0</version>
<scope>provided</scope>
</dependency>

As the WebSocket and JSON Processing APIs are not part of the Java EE 6 API, they need to be added to the project as dependencies.

The obvious but incorrect way to do this is to change the javax:javaee-web-api dependency to be version 7 so that they are provided as part of that dependency.  This introduces the Java EE 7 API to the application, including APIs such as  Servlet 3.1, EJB 3.2 and so forth which aren't yet supported by WebLogic Server.  Thus it presents the application developer with APIs to use that may not be available on the target server.

The correct way to add the WebSocket and JSON Processing APIs to the project is to add individual dependencies for each API using their individual published artifacts.

<dependency>
<groupId>javax.websocket</groupId>
<artifactId>javax.websocket-api</artifactId>
<version>1.0</version>
<scope>provided</scope>
</dependency>

<dependency>
<groupId>javax.json</groupId>
<artifactId>javax.json-api</artifactId>
<version>1.0</version>
<scope>provided</scope>
</dependency>

Using NetBeans, these dependencies can be quickly and correctly added using the code-assist dialog, which presents developers with options for how to resolve any missing classes that have been used in the code.



 Using the JSON Processing API with WebSocket Applications  The JSON Processing API is particularly useful for WebSocket application development since it provides a simple and efficient API for parsing JSON messages into Java objects and for generating JSON from Java objects.  These tasks are very typically performed in WebSocket applications using the Encoder and Decoder interfaces, which provides a mechanism for transforming custom Java objects into WebSocket messages for sending and converting WebSocket messages into Java objects.

An Encoder converts a Java object into a form able to send as a WebSocket message, typically using JSON as the format for use within Web browser based JavaScript clients.
package buttso.demo.cursor.websocket;

import java.util.logging.Level;
import java.util.logging.Logger;
import javax.json.Json;
import javax.json.JsonObject;
import javax.websocket.EncodeException;
import javax.websocket.Encoder;
import javax.websocket.EndpointConfig;

/**
* Convert a MouseMessage into a JSON payload.
*
* @author sbutton
*/
public class MouseMessageEncoder implements Encoder.Text{

private static final Logger logger = Logger.getLogger(MouseMessageEncoder.class.getName());

@Override
public String encode(MouseMessage mouseMessage) throws EncodeException {
logger.log(Level.FINE, mouseMessage.toString());
JsonObject jsonMouseMessage = Json.createObjectBuilder()
.add("X", mouseMessage.getX())
.add("Y", mouseMessage.getY())
.add("Id", mouseMessage.getId())
.build();
logger.log(Level.FINE, jsonMouseMessage.toString());
return jsonMouseMessage.toString();
}

@Override
public void init(EndpointConfig ec) {
// throw new UnsupportedOperationException("Not supported yet."); //To change body of generated methods, choose Tools | Templates.
}

@Override
public void destroy() {
// throw new UnsupportedOperationException("Not supported yet."); //To change body of generated methods, choose Tools | Templates.
}

}

An Decoder takes a String from a WebSocket message and turns it into a custom Java object, typically receiving a JSON payload that has been constructed and sent from a Web browser based JavaScript client.
package buttso.demo.cursor.websocket;

import java.io.StringReader;
import java.util.logging.Level;
import java.util.logging.Logger;
import javax.json.Json;
import javax.json.JsonObject;
import javax.websocket.Decoder;
import javax.websocket.EndpointConfig;

/**
* Converts a JSON payload into a MouseMessage
*
* @author sbutton
*/
public class MouseMessageDecoder implements Decoder.Text {

private static final Logger logger = Logger.getLogger(MouseMessageDecoder.class.getName());

@Override
public MouseMessage decode(String message) {
logger.log(Level.FINE, message);
JsonObject jsonMouseMessage = Json.createReader(new StringReader(message)).readObject();
MouseMessage mouseMessage = new MouseMessage();
mouseMessage.setX(jsonMouseMessage.getInt("X"));
mouseMessage.setY(jsonMouseMessage.getInt("Y"));
logger.log(Level.FINE, mouseMessage.toString());
return mouseMessage;
}

@Override
public boolean willDecode(String string) {
return true;
}

@Override
public void init(EndpointConfig ec) {
// throw new UnsupportedOperationException("Not supported yet."); //To change body of generated methods, choose Tools | Templates.
}

@Override
public void destroy() {
// throw new UnsupportedOperationException("Not supported yet."); //To change body of generated methods, choose Tools | Templates.
}

}

The Encoder and Decoder implementations are specified as configuration elements on a WebSocket Endpoint (server and/or client) and are automatically invoked to perform the required conversion task.
@ServerEndpoint(value = "/mouse", decoders = MouseMessageDecoder.class, encoders = MouseMessageEncoder.class)
public class MouseWebSocket {

private final Logger logger = Logger.getLogger(MouseWebSocket.class.getName());

...

@OnMessage
public void onMessage(Session peer, MouseMessage mouseMessage) throws EncodeException {
logger.log(Level.FINE, "MouseMessage {0} from {1}", new Object[]{mouseMessage, peer.getId()});
messages.add(mouseMessage);

for (Session others : peer.getOpenSessions()) {
try {
if (!others.getId().equals(peer.getId())) {
mouseMessage.setId((int) peer.getUserProperties().get("id"));
}
others.getBasicRemote().sendObject(mouseMessage);
} catch (IOException ex) {
Logger.getLogger(MouseWebSocket.class.getName()).log(Level.SEVERE, null, ex);
}

}
}

...
}
This example enables MouseMessage objects to be used in the WebSocket ServerEndpoint class to implement the required functionality and allow them to be transmitted in JSON format to and from clients. On the JavaScript client, the JSON representation is used to receive MouseMessages sent from the WebSocket Endpoint and to send MouseMessages to the same WebSocket Endpoint.

The JavaScript JSON API can be used to produce JSON representation of JavaScript objects as well as parse JSON payloads into JavaScript objects for use by the application code. For example, JavaScript logic can be used to send messages to WebSocket endpoints in JSON form using the JSON.stringify function and to create JavaScript objects from JSON messages received from a WebSocket message using the JSON.parse function.

    ...

document.onmousemove = function(e) {
if (tracking) {
// send current mouse position to websocket in JSON format
ws.send(JSON.stringify({X: e.pageX, Y: e.pageY}));
}
}


ws.onmessage = function(e) {
// convert JSON payload into JavaScript object
mouseMessage = JSON.parse(e.data);

// create page element using details from received
// MouseMessage from the WebSocket
point = document.createElement("div");
point.style.position = "absolute";
point.style.zIndex = mouseMessage.Id;
point.style.left = mouseMessage.X + "px";
point.style.top = mouseMessage.Y + "px";
point.style.color = colors[mouseMessage.Id];
point.innerHTML = "∗";
document.getElementById("mouser").appendChild(point);
};
When running the application, the mouse events are captured from the Web client, send to the WebSocket endpoint in JSON form, converted into MouseMessages, decorated with an ID representing the client the message came from and then broadcast out to any other connect WebSocket client to display.

A very crude shared-drawing board.

Simulatenous drawing in browser windows using WebSocket and JSON Processing API
