Today I’ll show trick how we can use branching in SQL*Plus.
Although I previously showed the conditional execution of scripts and it really can be used for branching, but today I’ll show how to do it without splitting the script into several smaller scripts. In contrast to the conditional script execution, I’ll use a different method.

It is very simple, as usual – if you want to execute only one part of script, you can just comment out all unnecessary. So depending on the conditions, we can execute a script which will start a comment.

Suppose we need to create a script, which, depending on the input parameter will be required to execute a specific query.
See how this can be done:
1. “test.sql”:

def param = &1

@if &param=1
   select 1 from dual;
/* end_if */

@if &param=2
   select 2 from dual;
/* end_if */

@if &param=3
   select 3 from dual;
/* end_if */

2. “if.sql”:

col do_next new_val do_next noprint;
select
      case
         when &1 then 'inc/null'
         else 'inc/comment_on'
      end as do_next
from dual;
@&do_next

3. “inc/comment_on.sql” contains only 2 chars:

/*

4. “inc/null.sql” is the same as in the previous examples – just empty file.

Ok, lets test it:

SQL> @test 1

         1
----------
         1


SQL> @test 2


         2
----------
         2


SQL> @test 3


         3
----------
         3

As you see, we got what we wanted. Please note that we have to close the multiline comments in the right places only(/* end_if */). So we cannot use in these parts another “*/”. But you can use it in another child scripts.

Same way we can make an analogue of switch/case:
“test2.sql”:

@switch &1

   @when 1 then
      select 1 from dual;
   /* end when */

   @when 2 then
      select 2 from dual;
   /* end when */

   @when 3 then
      select 3 from dual;
   /* end when */

/* end switch */

Spoiler:: switch.sql SelectShow

def switch_param=&1

Spoiler:: when.sql SelectShow

col do_next new_val do_next noprint;
select
      case
         when &1 = &switch_param then 'inc/null'
         else 'inc/comment_on'
      end as do_next
from dual;
@&do_next

SQL> @test2 2

         2
----------
         2

SQL> @test2 3

         3
----------
         3

We all used to iterators, recursions and branching in programming, but sql*plus does not have such commands. Today I will show how to do iterators/recusions.

Suppose we want to call a script 3 times. So it would be convenient if we can do it like:

@iterate 3 @some_script

It is very easy: We can recursively call the script by reducing variable until it is greater than zero. and if a variable is zero, then call an empty “NULL” script.
iterate.sql:

-- initializing input parameters as i showed in previous tips:
@inc/input_params_init.sql;
-- for example max number of input parameters = 14:
def _INIT_PARAMS = '"&3" "&4" "&5" "&6" "&7" "&8" "&9" "&10" "&11" "&12" "&13" "&14" "&15" "&16"'
def _ITER = "&1"

prompt ------   iteration &_ITER start: "@&2  -----------;
set termout off


col _SCRIPT    new_val _SCRIPT   noprint;
col _CONTINUE  new_val _CONTINUE noprint;
col _PARAMS    new_val _PARAMS   noprint;
select
   replace('"&3" "&4" "&5" "&6" "&7" "&8" "&9" "&10" "&11" "&12" "&13" "&14" "&15" "&16"'
          ,'${ITER}'
          ,'&_ITER'
          )          as "_PARAMS"
  ,case
      when &1 > 0 then 'iterate '||(&1 - 1)
      else 'inc/null'
   end               as "_CONTINUE"
  ,case
      when &1 > 0 then '&2'
      else 'inc/null'
   end               as "_SCRIPT"
from dual;
set termout on

@&_script            &_PARAMS
@&_CONTINUE &_SCRIPT &_INIT_PARAMS

As you see i also added option to pass iteration_number as input parameter, so we can call it like: @iterate 3 script.sql ${ITER}
And null.sql in “inc” directory is just empty file.

Lets test it:

SQL> $cat test.sql
select &1 a,'&2' b,'&3' c from dual;

SQL> @iterate 3 test.sql 1 2 3
------   iteration 3 start: "@test.sql  -----------

         A B C
---------- - -
         1 2 3

------   iteration 2 start: "@test.sql  -----------

         A B C
---------- - -
         1 2 3

------   iteration 1 start: "@test.sql  -----------

         A B C
---------- - -
         1 2 3

------   iteration 0 start: "@test.sql  -----------

SQL> @iterate 2 test.sql 1 2 ${ITER}
------   iteration 2 start: "@test.sql  -----------

         A B C
---------- - -
         1 2 2

------   iteration 1 start: "@test.sql  -----------

         A B C
---------- - -
         1 2 1

------   iteration 0 start: "@test.sql  -----------

Note that last string “iteration 0 start” just means that it is last empty call. I made this only for showing how we can do postprocessing after all iterations.
Ok, it works good, but with a little modification we can also add option to call such script with list of values too:
Spoiler:: final iterate.sql SelectShow

@inc/input_params_init.sql;

set termout off
def _INIT_PARAMS = '"&3" "&4" "&5" "&6" "&7" "&8" "&9" "&10" "&11" "&12" "&13" "&14" "&15" "&16"'
col _ITER_CURR new_val _ITER_CURR noprint
col _ITER_NEXT new_val _ITER_NEXT noprint
select
   case
      -- simple N iterations:
      when translate('&1','x0123456789','x') is null
         then '&1'
      -- list iteration:
      when substr('&1',1,1)='('
         then decode( instr('&1',',')
                     ,0,substr('&1',2,length('&1')-2)
                     ,substr('&1',2,instr('&1',',')-2)
                    )
   end "_ITER_CURR",
   case
      when translate('&1','x0123456789','x') is null
         then
            case
               when '&1'>1 then 'iterate '||('&1' - 1)
               else 'inc/null'
            end
      when substr('&1',1,1)='('
         then
            case
               when instr('&1',',')=0 or '&1'='()' then 'inc/null'
               else 'iterate '
                  ||'('
                  ||decode( instr('&1',',')
                           ,0,')'
                           ,substr('&1',instr('&1',',')+1)
                          )
            end
   end "_ITER_NEXT"
from dual;

set termout on
prompt ******   iteration &_ITER_CURR start: "@&2  ***********;
set termout off

col _SCRIPT    new_val _SCRIPT   noprint;
col _PARAMS    new_val _PARAMS   noprint;
select
   replace('"&3" "&4" "&5" "&6" "&7" "&8" "&9" "&10" "&11" "&12" "&13" "&14" "&15" "&16"'
          ,'${ITER}'
          ,'&_ITER_CURR'
          )          as "_PARAMS"
  ,case
      when nvl('&_ITER_CURR',0) in ('0','()') then 'inc/null'
      else '&2'
   end               as "_SCRIPT"
from dual;
set termout on

@&_script             &_PARAMS
@&_ITER_NEXT &_SCRIPT &_INIT_PARAMS

-- iterate by list of values  (7,3,10):
SQL> @iterate (7,3,10) test.sql 1 2 ${ITER}
******   iteration 7 start: "@test.sql  ***********

         A B C
---------- - -
         1 2 7

******   iteration 3 start: "@test.sql  ***********

         A B C
---------- - -
         1 2 3

******   iteration 10 start: "@test.sql  ***********

         A B C
---------- - --
         1 2 10

-- now with simple 2 iterations:
SQL> @iterate 2 test.sql 1 2 ${ITER}
******   iteration 2 start: "@test.sql  ***********

         A B C
---------- - -
         1 2 2

******   iteration 1 start: "@test.sql  ***********

         A B C
---------- - -
         1 2 1

I think you know the famous print_table procedure by Tom Kyte. It is really great, but a little hard(it requires create procedure or place it in anonymous block) and in last oracle versions we can do same with one simple query with xmltable/xmlsequence:

SQL> select *
  2  from
  3     xmltable( '/ROWSET/ROW/*'
  4               passing xmltype(cursor(select * from hr.employees where rownum<3))
  5               columns
  6                  col varchar2(100) path 'name()'
  7                 ,val varchar2(100) path '.'
  8        );

COL                            VAL
------------------------------ ------------------------------------------------------
EMPLOYEE_ID                    198
FIRST_NAME                     Donald
LAST_NAME                      OConnell
EMAIL                          DOCONNEL
PHONE_NUMBER                   650.507.9833
HIRE_DATE                      21-JUN-07
JOB_ID                         SH_CLERK
SALARY                         2600
MANAGER_ID                     124
DEPARTMENT_ID                  50
EMPLOYEE_ID                    199
FIRST_NAME                     Douglas
LAST_NAME                      Grant
EMAIL                          DGRANT
PHONE_NUMBER                   650.507.9844
HIRE_DATE                      13-JAN-08
JOB_ID                         SH_CLERK
SALARY                         2600
MANAGER_ID                     124
DEPARTMENT_ID                  50

20 rows selected.

It is very easy, but for conveniency we need to add “rownum”:

SQL> select *
  2  from
  3     xmltable( 'for $a at $i in /ROWSET/ROW
  4                   ,$r in $a/*
  5                     return element ROW{
  6                                       element ROW_NUM{$i}
  7                                      ,element COL_NAME{$r/name()}
  8                                      ,element COL_VALUE{$r/text()}
  9                                      }'
 10               passing xmltype(cursor(select * from hr.employees where rownum<3))
 11               columns
 12                  row_num   int
 13                 ,col_name  varchar2(30)
 14                 ,col_value varchar2(100)
 15        );

   ROW_NUM COL_NAME                       COL_VALUE
---------- ------------------------------ ------------------------------------------
         1 EMPLOYEE_ID                    198
         1 FIRST_NAME                     Donald
         1 LAST_NAME                      OConnell
         1 EMAIL                          DOCONNEL
         1 PHONE_NUMBER                   650.507.9833
         1 HIRE_DATE                      21-JUN-07
         1 JOB_ID                         SH_CLERK
         1 SALARY                         2600
         1 MANAGER_ID                     124
         1 DEPARTMENT_ID                  50
         2 EMPLOYEE_ID                    199
         2 FIRST_NAME                     Douglas
         2 LAST_NAME                      Grant
         2 EMAIL                          DGRANT
         2 PHONE_NUMBER                   650.507.9844
         2 HIRE_DATE                      13-JAN-08
         2 JOB_ID                         SH_CLERK
         2 SALARY                         2600
         2 MANAGER_ID                     124
         2 DEPARTMENT_ID                  50

20 rows selected.

Now we can create simple script for it with formatting:
Spoiler:: print_table.sql SelectShow

-- show output
set termout on
-- but without echo
set echo off
-- without newpage on start:
set embedded on
-- scrolling control
set pause on
-- two lines between rows:
set newpage 2
-- text for prompt after each page:
set pause "Press Enter to view next row..."
-- new page on new "row_num"
break on row_num skip page

-- main query:
select *
from
   xmltable( 'for $a at $i in /ROWSET/ROW
                 ,$r in $a/*
                   return element ROW{
                                     element ROW_NUM{$i}
                                    ,element COL_NAME{$r/name()}
                                    ,element COL_VALUE{$r/text()}
                                    }'
             passing xmltype(cursor( &1 ))
             columns
                row_num   int
               ,col_name  varchar2(30)
               ,col_value varchar2(100)
      );
-- disabling pause and breaks:
set pause off
clear breaks

Usage example:
As you see script works fine, but it is require to pass query as parameter, though sometimes it is not so convenient. For example if we want started query and later decided to show it with print_table. In that case we can create scripts with tricks from previous part:
Spoiler:: print_last.sql SelectShow

store set settings.sql replace
-- saving previous query:
save tmp.sql replace

-- OS-dependent removing trailing slash from file, choose one:
-- 1. for *nix through head:
!head -1 tmp.sql >tmp2.sql

-- 2. for for *nix through grep:
--!grep -v tmp.sql >tmp2.sql

-- 3. for windows without grep and head:
-- $cmd /C findstr /v /C:"/" tmp.sql > tmp2.sql

-- 4. for windows with "head"(eg from cygwin)
--$cmd /C head -1 tmp.sql > tmp2.sql

-- 5. for windows with "grep":
--$cmd /C grep -v "/" tmp.sql > tmp2.sql



-- same setting as in print_table:
set termout on echo off embedded on pause on newpage 2
set pause "Press Enter to view next row..."
break on row_num skip page

-- main query:
select *
from
   xmltable( 'for $a at $i in /ROWSET/ROW
                 ,$r in $a/*
                   return element ROW{
                                     element ROW_NUM{$i}
                                    ,element COL_NAME{$r/name()}
                                    ,element COL_VALUE{$r/text()}
                                    }'
             passing dbms_xmlgen.getxmltype(
             q'[
               @tmp2.sql
             ]'
             )
             columns
                row_num   int
               ,col_name  varchar2(30)
               ,col_value varchar2(100)
      );
-- disabling pause and breaks:
set pause off
clear breaks
@settings.sql

Example: Spoiler: SelectShow

SQL> select * from hr.employees where rownum<3;

EMPLOYEE_ID FIRST_NAME           LAST_NAME                 EMAIL                     PHONE_NUMBER      HIRE_DATE JOB_ID    SALARY COMMISSION_PCT MANAGER_ID DEPARTMENT_ID
----------- -------------------- ------------------------- ------------------------- -------------------- --------- ---------- ---------- -------------- ---------- -------------
        198 Donald               OConnell                  DOCONNEL                  650.507.9833         21-JUN-07 SH_CLERK         2600                       124            50
        199 Douglas              Grant                     DGRANT                    650.507.9844         13-JAN-08 SH_CLERK         2600                       124            50

Elapsed: 00:00:00.01
SQL> @print_last
Wrote file settings.sql
Wrote file tmp.sql

   ROW_NUM COL_NAME                       COL_VALUE
---------- ------------------------------ ----------------------------------------------------------------------------------------------------
         1 EMPLOYEE_ID                    198
           FIRST_NAME                     Donald
           LAST_NAME                      OConnell
           EMAIL                          DOCONNEL
           PHONE_NUMBER                   650.507.9833
           HIRE_DATE                      21-JUN-07
           JOB_ID                         SH_CLERK
           SALARY                         2600
           MANAGER_ID                     124
           DEPARTMENT_ID                  50
Press Enter to view next row...

alter session set events '19027 trace name context forever, level 0x1';

A nice toy, but i’m sure it will not tolerate big data.

It is absolutely true, because at first, “xmltype(cursor(…))” aggregated data as xmltype, and only then xmltable returns data.
But I use print_table for small amount of data only, and in case of when i want to see sample of data, i usually add limitation by rownum, which also convenient because it automatically changes optimizer mode with enabled parameter “_optimizer_rownum_pred_based_fkr” (it is default):

SQL> @param_ rownum

NAME                               VALUE   DEFLT  TYPE     DESCRIPTION
---------------------------------- ------- ------ -------- ------------------------------------------------------
_optimizer_rownum_bind_default     10      TRUE   number   Default value to use for rownum bind
_optimizer_rownum_pred_based_fkr   TRUE    TRUE   boolean  enable the use of first K rows due to rownum predicate
_px_rownum_pd                      TRUE    TRUE   boolean  turn off/on parallel rownum pushdown optimization

However, we can easily change the our query to make it optimally with a lot of data too:

select row_num
      ,t2.*
from
   (select rownum row_num
         , column_value x
    from table(xmlsequence(cursor( &1 )))
   ) t1
  ,xmltable( '/ROW/*'
             passing t1.x
             columns
                col_num for ordinality
               ,col_name  varchar2(30) path 'name()'
               ,col_value varchar2(100) path '.'
      )(+) t2;

Lets test it with pipelined function which will pipe rows infinitely and log count of fetched rows:

-- drop table xt_log purge;
-- drop function f_infinite;

create table xt_log(n int);

create function f_infinite
   return sys.ku$_objnumset pipelined
as
   i int:=0;
   pragma autonomous_transaction;
begin
   loop
      i:=i+1;
      insert into xt_log values(i);
      commit;
      pipe row(i);
   end loop;

exception
   when NO_DATA_NEEDED then
      commit;
end;
/

Spoiler:: New version of print_table: print_table2.sql SelectShow

-- set arraysize for minimal value, so sqlplus did not fetch extra rows:
set arraysize 2
-- show output
set termout on
-- but without echo
set echo off
-- without newpage on start:
set embedded on
-- scrolling control
set pause on
-- two lines between rows:
set newpage 2
-- text for prompt after each page:
set pause "Press Enter to view next row..."
-- new page on new "row_num"
break on row_num skip page

-- main query:
select row_num
      ,t2.*
from
   (select rownum row_num
         , column_value x
    from table(xmlsequence(cursor( &1 )))
   ) t1
  ,xmltable( '/ROW/*'
             passing t1.x
             columns
                col_num for ordinality
               ,col_name  varchar2(30) path 'name()'
               ,col_value varchar2(100) path '.'
      )(+) t2;
-- disabling pause and breaks:
set pause off
clear breaks

SQL> select * from xt_log;

no rows selected

SQL> @print_table2 "select * from table(f_infinite)"
Press Enter to view next row...


   ROW_NUM    COL_NUM COL_NAME                       COL_VALUE
---------- ---------- ------------------------------ -----------
         1          1 COLUMN_VALUE                   1
Press Enter to view next row...


   ROW_NUM    COL_NUM COL_NAME                       COL_VALUE
---------- ---------- ------------------------------ -----------
         2          1 COLUMN_VALUE                   2
Press Enter to view next row...


   ROW_NUM    COL_NUM COL_NAME                       COL_VALUE
---------- ---------- ------------------------------ -----------
         3          1 COLUMN_VALUE                   3
Press Enter to view next row...


   ROW_NUM    COL_NUM COL_NAME                       COL_VALUE
---------- ---------- ------------------------------ -----------
         4          1 COLUMN_VALUE                   4
Press Enter to view next row...

   ROW_NUM    COL_NUM COL_NAME                       COL_VALUE
         5          1 COLUMN_VALUE                   5
Press Enter to view next row...


6 rows selected.
-------------------------------
SQL> select * from xt_log;

         N
----------
         1
         2
         3
         4
         5
         6
         7

7 rows selected.

PS. Full scripts:
1. Simple: print_table.sql
2. For big queries: print_table2.sql

JDeveloper 11.1.1.7 just hit the streets and among the new features it contains are several new data visualization ADF Faces components including timeline, treemap, and sunburst.

I got to play with the sunburst component a while back while building some internal demos - so I thought I'll provide a quick overview of some of the things you can do with it, and how to work with it at design time.

The sunburst component is used to visually show numerical data along one or two axises relating to something. One axis of data will show as the size of slices and the other data will show as a color. You can think about it as a two axis pie chart. The sunburst also allow for drilling into detail levels.

In the below example I'm showing just one set of data that has to do with the total orders broken in several levels - region->country->customer.

So here is the demo:

For those interested in the actual JSF code it is below:

          <dvt:sunburst id="s1" value="#{bindings.RegionSales1.treeModel}"
                        var="row" animationOnDataChange="alphaFade"
                        animationOnDisplay="fan" displayLevelsChildren="0"
                        styleClass="AFStretchWidth"
                        inlineStyle="height:620.0px;" legendSource="ag1"
                        colorLabel="Sales">
            <af:switcher facetName="#{row.hierTypeBinding.name}" id="s2">
              <f:facet name="RegionSales10">
                <dvt:sunburstNode value="#{row.Total}" label="#{row.Name}"
                                  id="sn3" drilling="insert">
                  <dvt:attributeGroups id="ag1" value="#{row.Total}"
                                       label="#{row.Total}" type="color"
                                       attributeType="continuous" minValue="0"
                                       maxValue="3000000" minLabel="0"
                                       maxLabel="3M">
                    <f:attribute name="color1" value="11AA55"/>
                    <f:attribute name="color2" value="44BB77"/>
                    <f:attribute name="color3" value="77DD99"/>
                  </dvt:attributeGroups>
                </dvt:sunburstNode>
              </f:facet>
              <f:facet name="RegionSales11">
                <dvt:sunburstNode value="#{row.Total}" label="#{row.Country}"
                                  id="sn1" drilling="insert">
                  <dvt:attributeGroups id="ag2" value="#{row.Total}"
                                       label="#{row.Total}" type="color"
                                       attributeType="continuous" minValue="0"
                                       maxValue="2800000" minLabel="0"
                                       maxLabel="2.8M">
                    <f:attribute name="color1" value="11AA55"/>
                    <f:attribute name="color2" value="44BB77"/>
                    <f:attribute name="color3" value="77DD99"/>
                  </dvt:attributeGroups>
                </dvt:sunburstNode>
              </f:facet>
              <f:facet name="RegionSales12">
                <dvt:sunburstNode value="#{row.Total}" label="#{row.Name1}"
                                  id="sn2" drilling="insertAndReplace"/>
              </f:facet>
            </af:switcher>
          </dvt:sunburst>

If you are using SQL*Plus, you are likely to use the input parameters. And if you omit one of them, SQL*Plus will show prompt for it, like this:

SQL> get test.sql
  1  select 'Input variable 1 = &1' from dual
  2  union all
  3  select 'Input variable 2 = &2' from dual
  4  union all
  5* select 'Input variable 3 = &3' from dual
SQL> @test var1 var2
Enter value for 3:

'INPUTVARIABLE1=VAR1'
-----------------------
Input variable 1 = var1
Input variable 2 = var2
Input variable 3 =

Elapsed: 00:00:00.01

It is allright, if all variables are needed, but what if we don’t want to press enter for all omitted variables or specify they(especially if script can be start in silent, non interactive mode) and want to use default values for omitted variables or these variables can be unnecessary?
Strictly speaking, there are many different techniques for solving it, see some of them:
Spoiler:: Comma-separated params SelectShow

SQL> get test1
  1  col var1 new_value var1 noprint
  2  col var2 new_value var2 noprint
  3  col var3 new_value var3 noprint
  4  set termout off
  5  with any_splitting_technique as (
  6       select *
  7       from xmltable('ora:tokenize(.,",")[position()>1]'
  8                      passing ','||'&1'
  9                      columns
 10                        i for ordinality
 11                       ,"." varchar2(30)
 12                    )
 13  )
 14  select
 15    nvl("1",'default1') var1
 16   ,nvl("2",'default2') var2
 17   ,nvl("3",'default3') var3
 18  from any_splitting_technique
 19  pivot (max(".") for i in (1,2,3))
 20  /
 21  set termout on
 22* prompt var1 = &var1, var2 = &var2, var3 = &var3;
SQL> @test1 1,2,3
var1 = 1, var2 = 2, var3 = 3
SQL> @test1 1,2
var1 = 1, var2 = 2, var3 = default3

Spoiler:: With SPOOL and DEFINE SelectShow

SQL> get test2
  1  set termout off
  2  spool tmp.sql
  3  def 1
  4  def 2
  5  def 3
  6  spool off
  7  col var1 new_value var1
  8  col var2 new_value var2
  9  col var3 new_value var3
 10  with tmp as (
 11  select '
 12  @tmp.sql
 13  ' params from dual
 14  )
 15  select
 16    nvl(regexp_substr(params,'DEFINE 1\s+ = "([^"]*)',1,1,'i',1),'default1') var1
 17  , nvl(regexp_substr(params,'DEFINE 2\s+ = "([^"]*)',1,1,'i',1),'default2') var2
 18  , nvl(regexp_substr(params,'DEFINE 3\s+ = "([^"]*)',1,1,'i',1),'default3') var3
 19  from tmp
 20  ;
 21  col var1 clear;
 22  col var2 clear;
 23  col var3 clear;
 24  set termout on
 25  prompt var1 = &var1, var2 = &var2, var3 = &var3;
 26  undef 1
 27  undef 2
 28* undef 3
 29  .
SQL> @test2 1 2 3
var1 = 1, var2 = 2, var3 = 3
SQL> @test2 1 2
var1 = 1, var2 = 2, var3 = default3

Last example also shows a very useful way to read file into a variable.
But i think, the best option for initializing parameters is the solution by Vladimir Begun:

SQL> get test3
  1  set termout off
  2  COLUMN 1 NEW_VALUE 1    noprint
  3  COLUMN 2 NEW_VALUE 2    noprint
  4  COLUMN 3 NEW_VALUE 3    noprint
  5  SELECT '' "1", '' "2", '' "3" FROM dual WHERE 1=0;
  6  SELECT nvl('&1','default1') "1"
  7       , nvl('&2','default2') "2"
  8       , nvl('&3','default3') "3"
  9    FROM dual;
 10  col var1 clear;
 11  col var2 clear;
 12  col var3 clear;
 13  set termout on
 14  prompt var1 = &1, var2 = &2, var3 = &3;
 15  undef 1
 16  undef 2
 17* undef 3
 18  .
SQL> @test3 1 2 3
var1 = 1, var2 = 2, var3 = 3
SQL> @test3 1 2
var1 = 1, var2 = 2, var3 = default3

So i can create 2 include files – for execution at the start and at the end of all scripts. I created directory “inc” for include files and files:
Spoiler:: inc/s_begin.sql SelectShow

store set splus_restore.sql replace
set termout off
COLUMN  1  NEW_VALUE  1    noprint
COLUMN  2  NEW_VALUE  2    noprint
COLUMN  4  NEW_VALUE  4    noprint
COLUMN  3  NEW_VALUE  3    noprint
COLUMN  5  NEW_VALUE  5    noprint
COLUMN  6  NEW_VALUE  6    noprint
COLUMN  7  NEW_VALUE  7    noprint
COLUMN  8  NEW_VALUE  8    noprint
COLUMN  9  NEW_VALUE  9    noprint
COLUMN 10  NEW_VALUE 10    noprint
COLUMN 11  NEW_VALUE 11    noprint
COLUMN 12  NEW_VALUE 12    noprint
COLUMN 13  NEW_VALUE 13    noprint
COLUMN 14  NEW_VALUE 14    noprint
COLUMN 15  NEW_VALUE 15    noprint
COLUMN 16  NEW_VALUE 16    noprint


SELECT ''  "1", '' "5", ''  "9", '' "13"
      ,''  "2", '' "6", '' "10", '' "14"
      ,''  "3", '' "7", '' "11", '' "15"
      ,''  "4", '' "8", '' "12", '' "16"
  FROM dual
 WHERE 1=0;
set termout on;

and Spoiler:: inc/s_end.sql SelectShow

undef 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
@splus_restore;

And for example get_index.sql: Spoiler:: get_index.sql SelectShow

@inc/s_begin;
col table_owner format a12
col column_name format a30
col index_owner format a12
col index_name  format a30

col "#" format 99
break on table_owner on table_name on index_owner on index_name on partition_name on mbytes on bytes on blocks
select
         ic.table_owner
        ,ic.table_name
        ,ic.index_owner
        ,ic.index_name
        ,s.partition_name
        ,round(s.bytes/1024/1024) mbytes
        ,s.blocks
        ,ic.column_position "#"
        ,decode(ic.column_position,1,'','  ,')||ic.column_name column_name
from dba_ind_columns ic
    ,dba_segments s
where
     upper(ic.table_name) like upper('&1')
 and upper(ic.table_owner) like nvl(upper('&2'),'%')
 and s.owner        = ic.index_owner
 and s.segment_name = ic.index_name
order by
         1,2,3,4,8
/
clear break;
col "#" clear;
@inc/s_end;

Spoiler:: Sample output SelectShow

SQL> @get_indexes wrh$%tab%stat xtender
Wrote file splus_restore.sql

no rows selected

Elapsed: 00:00:05.79
SQL> @get_indexes wrh$%undostat
Wrote file splus_restore.sql

TABLE_OWNER  TABLE_NAME     INDEX_OWNER  INDEX_NAME        PARTITION_NAME  MBYTES  BLOCKS   # COLUMN_NAME
------------ -------------- ------------ ----------------- -------------- ------- ------- --- --------------------
SYS          WRH$_UNDOSTAT  SYS          WRH$_UNDOSTAT_PK                       0      16   1 BEGIN_TIME
                                                                                            2   ,END_TIME
                                                                                            3   ,DBID
                                                                                            4   ,INSTANCE_NUMBER

Previously i showed not obvious example with hint “INDEX_STATS(“OWNER”.”TABLE_NAME”, “INDEX_NAME”, scale, blocks=X, rows=Y)“. Strictly speaking i don’t know how exactly cbo calculates number of index leaf blocks in that case: in those examples they was 1981 for “blocks=1, rows=50″ and 49525 for “blocks=5, rows=10″.
But i know that with “INDEX_STATS(“OWNER”.”TABLE_NAME”, “INDEX_NAME”, scale, blocks=X)” i can set exact blocks number.
Also those test-cases didn’t show when occurs decision changing. So todays my test will show it.

BTW, it is very interesting that a turning point was _very_large_object_threshold, but not 5 * _small_table_threshold. AFAIK, direct path reads decision depends on many factors (such as number of object blocks in buffer cache), and would be great to know all of them.
You can download script as file: controlling_direct_reads_with_profiles.sql
Spoiler:: Test code SelectShow

/** SQLPLUS Example of controlling adaptive serial direct path reads through SQL profiles.
*/
set serverout on termout on timing off feed off;
clear scr;
def _IF_XT_RUNSTATS_EXISTS="--"
col if_xt_runstats_exists new_value _IF_XT_RUNSTATS_EXISTS noprint;
select decode(count(*),1,'  ','--') if_xt_runstats_exists
from all_objects where object_name='XT_RUNSTATS' and rownum=1;
/**
 * Main test.
 * You can use it also in other clients,
 * but in that case you have to manually
 * set substitution variable _IF_XT_RUNSTATS_EXISTS:
 *  if you have not this package - to "--"
 *  otherwise                    - to space(" ")
 * Latest version of XT_RUNSTATS you can get from:
 *  https://github.com/xtender/xt_runstats
 */

declare

   C_SQL_TEXT      constant varchar2(300):='SELECT SUM(A) FROM XT_IFFS T';
   C_PROFILE_NAME  constant varchar2(30) :='PRF_ADPR_TEST';
   v_small_table_threshold        int;
   v_db_block_buffers             int;
   v_very_large_object_threshold  int;
   v__db_cache_size               int;

   procedure exec(p varchar2) is
     e_table_is_not_created_yet exception;
     e_index_is_not_created_yet exception;
     pragma exception_init(e_table_is_not_created_yet, -942);
     pragma exception_init(e_index_is_not_created_yet, -1418);
   begin
     execute immediate p;
   exception
      when e_table_is_not_created_yet
        or e_index_is_not_created_yet
        then null;
   end;

   /** Creating table and setting stats */
   procedure create_table is
   begin
     exec('drop table xt_iffs purge');
     exec('create table xt_iffs as
           with gen as(
                       select level a,mod(level,10) b,lpad(1,50,1) c
                       from dual
                       connect by level<=1e3
           )
           select gen.*
           from gen,gen gen2'
         );
     --dbms_stats.set_table_stats('','XT_IFFS',numrows => 1e6,numblks => 5e5,avgrlen => 800);
     dbms_stats.gather_table_stats('','XT_IFFS');
   end;

   /** Recreating index and setting stats */
   procedure create_index is
   begin
     exec('drop index ix_iffs');
     exec('create index ix_iffs on xt_iffs(a,b)');
     dbms_stats.set_index_stats('','IX_IFFS',numrows => 1e6,numlblks => 1e4);
   end;

   /** Setting index numblks for query through SQL profile */
   procedure set_numblks(p_numblks int) is
     e_profile_not_created_yet  exception;
     pragma exception_init( e_profile_not_created_yet, -13833);
   begin
     begin
        dbms_sqltune.drop_sql_profile(C_PROFILE_NAME);
     exception when e_profile_not_created_yet then null;
     end;
     dbms_sqltune.import_sql_profile(
        sql_text    => C_SQL_TEXT,
        profile     => sys.sqlprof_attr(
                                 'INDEX_FFS(@"SEL$1" "T"@"SEL$1" ("XT_IFFS"."A"))'
                                ,'INDEX_STATS("'||user||'"."XT_IFFS", "IX_IFFS", scale, blocks='||p_numblks||')'
                       ),
        category     => 'DEFAULT',
        name        => C_PROFILE_NAME,
        force_match => false,
        replace     => true
     );
   end;

   procedure test( p_description varchar2
                 , p_numblks int default null) is

     type t_seg_stat is
        table of number
        index by v$segstat_name.name%type;
     -- segments statistics by index:
     cursor c_stats is
        select sn.name,nvl(st.value,0) value
        from v$segstat_name sn
            ,v$segment_statistics st
        where
              sn.statistic#     = st.statistic#(+)
          and st.owner(+)       = user
          and st.object_name(+) ='IX_IFFS';
     -- var for previous stats:
     v_pre     t_seg_stat;
     v_delta   number;
     n         number;
   begin
     dbms_output.put_line('-');
     dbms_output.put_line('-');
     dbms_output.put_line(lpad('-',150,'-'));
     dbms_output.put_line(lpad('-',150,'-'));
     dbms_output.put_line(  '###                '
                         || p_description||': '
                         ||nvl(to_char(p_numblks),'default')||' blocks');
     dbms_output.put_line('-');

     create_index;
     -- if p_numblks is null then default stats used
     if p_numblks is not null then
       set_numblks(p_numblks);
     end if;
     execute immediate C_SQL_TEXT into n;
     exec('alter system flush buffer_cache');
     -- saving segment statistics
     for r in c_stats loop
        v_pre(r.name) := r.value;
     end loop;

     &_IF_XT_RUNSTATS_EXISTS  xt_runstats.init(p_latches => false);
     -- executing query
     execute immediate C_SQL_TEXT into n;
   &_IF_XT_RUNSTATS_EXISTS  xt_runstats.snap;
   &_IF_XT_RUNSTATS_EXISTS  xt_runstats.print(
   &_IF_XT_RUNSTATS_EXISTS     p_stats_mask => '(reads (cache|direct)\.)|index fast full scans \((full|direct)'
   &_IF_XT_RUNSTATS_EXISTS    ,p_sta_diff_pct => 0);

     -- printing segments stats delta:
     for r in c_stats loop
        v_delta:= r.value - v_pre(r.name);
        if v_delta!=0 then
          dbms_output.put_line( rpad(r.name,40,'.')||v_delta );
        end if;
     end loop;
   end;

   procedure load_and_print_params is
   begin
      select
         max(decode(a.ksppinm, '_small_table_threshold'       ,b.ksppstvl))
        ,max(decode(a.ksppinm, '_db_block_buffers'            ,b.ksppstvl))
        ,max(decode(a.ksppinm, '_very_large_object_threshold' ,b.ksppstvl))
        ,max(decode(a.ksppinm, '__db_cache_size'              ,b.ksppstvl))
         into v_small_table_threshold,v_db_block_buffers,v_very_large_object_threshold,v__db_cache_size
      from
        sys.x$ksppi a
       ,sys.x$ksppcv b
      where
           a.indx = b.indx
       and a.ksppinm in('_small_table_threshold','_db_block_buffers','_very_large_object_threshold','__db_cache_size');
      dbms_output.put_line('_small_table_threshold       = '||v_small_table_threshold);
      dbms_output.put_line('_db_block_buffers            = '||v_db_block_buffers);
      dbms_output.put_line('_very_large_object_threshold = '||v_very_large_object_threshold);
      dbms_output.put_line('__db_cache_size              = '||v__db_cache_size);

   end;
begin
  create_table;
  load_and_print_params;

  test( '_very_large_object_threshold + 1'
       ,v_db_block_buffers * v_very_large_object_threshold/100 + 1 );
  test( '_very_large_object_threshold'
       ,v_db_block_buffers * v_very_large_object_threshold/100     );
  test( '_very_large_object_threshold - 1'
       ,v_db_block_buffers * v_very_large_object_threshold/100 - 1 );

  test( '_db_block_buffers + 1'
       ,v_db_block_buffers + 1 );
  test( '_db_block_buffers - 1'
       ,v_db_block_buffers - 1 );

  test( '_small_table_threshold * 5 + 1'
       ,v_small_table_threshold * 5 + 1 );
  test( '_small_table_threshold * 5 - 1'
       ,v_small_table_threshold * 5 - 1 );

  test( ' 1 block ', 1);
  test( ' Default ', null);

  test( ' Again _very_large_object_threshold + 1'
       ,v_db_block_buffers * v_very_large_object_threshold/100 + 1 );
  test( ' Again _very_large_object_threshold'
       ,v_db_block_buffers * v_very_large_object_threshold/100     );

end;
/

Spoiler:: Test results SelectShow

_small_table_threshold       = 166
_db_block_buffers            = 8347
_very_large_object_threshold = 500
__db_cache_size              = 4194304
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _very_large_object_threshold + 1: 41736 blocks
-
################     Results:      ##################
Run #  01 ran in 11 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |              1
physical reads direct................... |          2,491
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              1
##########################################################
-
logical reads...........................2496
physical reads..........................2492
physical read requests..................86
physical reads direct...................2491
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _very_large_object_threshold: 41735 blocks
-
################     Results:      ##################
Run #  01 ran in 6 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2496
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _very_large_object_threshold - 1: 41734 blocks
-
################     Results:      ##################
Run #  01 ran in 11 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          3,386
physical reads direct................... |              1
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2512
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _db_block_buffers + 1: 8348 blocks
-
################     Results:      ##################
Run #  01 ran in 6 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2512
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _db_block_buffers - 1: 8346 blocks
-
################     Results:      ##################
Run #  01 ran in 8 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2512
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _small_table_threshold * 5 + 1: 831 blocks
-
################     Results:      ##################
Run #  01 ran in 6 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2512
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                _small_table_threshold * 5 - 1: 829 blocks
-
################     Results:      ##################
Run #  01 ran in 7 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2496
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                 1 block : 1 blocks
-
################     Results:      ##################
Run #  01 ran in 6 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2512
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                 Default : default blocks
-
################     Results:      ##################
Run #  01 ran in 7 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2496
physical reads..........................2494
physical read requests..................95
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                 Again _very_large_object_threshold + 1: 41736 blocks
-
################     Results:      ##################
Run #  01 ran in 6 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |              1
physical reads direct................... |          2,491
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              1
##########################################################
-
logical reads...........................2496
physical reads..........................2492
physical read requests..................86
physical reads direct...................2491
segment scans...........................1
-
-
------------------------------------------------------------------------------
------------------------------------------------------------------------------
###                 Again _very_large_object_threshold: 41735 blocks
-
################     Results:      ##################
Run #  01 ran in 7 hsecs
##########################################################
Statistics                               | Run # 1
##########################################################
physical reads cache.................... |          2,494
physical reads direct................... |              0
index fast full scans (full)............ |              1
index fast full scans (direct read)..... |              0
##########################################################
-
logical reads...........................2496
physical reads..........................2494
physical read requests..................95
segment scans...........................1

PL/SQL procedure successfully completed.

apex_application.g_excel_format = FALSE

apex_application.g_excel_format = TRUE

ORA-01722: invalid number

A couple days ago i had very interesting quiz, which is not resolved yet.
Look at this simplified query:

  select *
  from xt1,xt2
  where
       xt1.b=10
   and xt1.a=xt2.a
   and xt2.b in (1,2);

PLAN_TABLE_OUTPUT
----------------------------------------------------------------------------------------
Plan hash value: 2715236140

----------------------------------------------------------------------------------------
| Id  | Operation                     | Name   | Rows  | Bytes | Cost (%CPU)| Time     |
----------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT              |        |   100 | 36900 |   501   (0)| 00:00:07 |
|   1 |  NESTED LOOPS                 |        |       |       |            |          |
|   2 |   NESTED LOOPS                |        |   100 | 36900 |   501   (0)| 00:00:07 |
|   3 |    TABLE ACCESS BY INDEX ROWID| XT1    |   100 | 31000 |   101   (0)| 00:00:02 |
|*  4 |     INDEX RANGE SCAN          | IX_XT1 |   100 |       |     1   (0)| 00:00:01 |
|   5 |    INLIST ITERATOR            |        |       |       |            |          |
|*  6 |     INDEX RANGE SCAN          | IX_XT2 |     1 |       |     3   (0)| 00:00:01 |
|   7 |   TABLE ACCESS BY INDEX ROWID | XT2    |     1 |    59 |     4   (0)| 00:00:01 |
----------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   4 - access("XT1"."B"=10)
   6 - access("XT1"."A"="XT2"."A" AND ("XT2"."B"=1 OR "XT2"."B"=2))

Spoiler:: Full test case SelectShow

create table xt1 as
select
   level a
 , mod(level,1000) b
 , lpad(1,300,1) padding
from dual
connect by level<=1e5;

create index ix_xt1 on xt1(b);

create table xt2 as
select
   level        a
 , mod(level,5) b
 , lpad(1,50,1) padding
from dual
connect by level<=1e6;

alter table xt2
  add constraint uq_xt2
  unique (a)
  using index(create index ix_xt2 on xt2(a,b));

exec dbms_stats.gather_table_stats('','XT1',cascade=>true);
exec dbms_stats.gather_table_stats('','XT2',cascade=>true);

explain plan for
select *
from xt1,xt2
where
     xt1.b=10
 and xt1.a=xt2.a
 and xt2.b in (1,2);

@?/rdbms/admin/utlxpls.sql

SQL> select *
  2  from xt1,xt2
  3  where
  4       xt1.b=10
  5   and xt1.a=xt2.a
  6   and xt2.b in (1,2);

no rows selected

Statistics
----------------------------------------------------------
        ...
        505  consistent gets
SQL> -- without inlist iterator:
SQL> select *
  2  from xt1,xt2
  3  where
  4       xt1.b=10
  5   and xt1.a=xt2.a
  6   and xt2.b+0 in (1,2);

no rows selected

Statistics
----------------------------------------------------------
        ...
        305  consistent gets
