Hackathon weekend at Fishbowl Solutions – Google Vision, Slack, and Email Integrations with Oracle WebCenter

It’s hackathon weekend at Fishbowl Solutions. Fishbowl’s consulting and development teams – the hackers – along with members of the sales and marketing teams join forces to collaborate on and develop new software applications. While the overall goal of the hackathon may be to produce usable software, the event also is a great learning opportunity for participants and results in a lot of fun.

This is Fishbowl’s 4th annual hackathon and previous events have produced “beta” software that eventually evolved into shippable software components that benefited customers. Here are recaps on the 2012 and 2014 events.

This year there were over 16 different ideas, and out of those 3 teams were formed to develop the following:

  • Oracle WebCenter Portal and Slack integration – Slack is a popular collaboration tool for the enterprise that enables members to communicate across channels (specific topics), send direct messages, and drag and drop files for sharing. Integrating Slack with WebCenter Portal brings its popular features and ease of use directly in context of a user’s portal session, ensuring that collaboration is easy and reducing the amount of switching between applications to communicate with others – leaving the portal to send an email, for example.

WebCenter Portal and Slack Integration Team – Andy Weaver and Dan Haugen



  • Oracle WebCenter Content and Google Vision integration – This integration would enable the tagging of images upon check-in. The Google Vision API enables applications to understand the content of images by encapsulating machine learning models in an easy to use REST API. Using this technology, images are auto-classified into thousands of categories (e.g., “sailboat”, “lion”, “Eiffel Tower”). For example, you might check in a picture of a knit hat and it would be tagged with xKeywords of “hat”, “knit hat”, and “fashion accessories” without any human tagging. To further automate image discovery, the GSA can be used to map related terms so that searches for “beanie”, “stocking cap”, or “winter hat”, could also return the image. This tagging automation would have great implications for Oracle WebCenter customers that are using it for Digital Asset Management.

WebCenter Content and Google Vision Integration Team – Kim Negaard and Greg Bollom


  • Oracle WebCenter Content Email Check in - This integration would enable emails with attachments to be checked in to WebCenter Content automatically. Instead of the user having to check in the email itself, and then relating each attachment to the associated email, which results in additional check in steps, the emails and attachments would be parsed out and sent to a user workspaces in WebCenter. From there, users can tag and validate that the email should be checked in with the appropriate attachments – either from their desktops or mobile device.
WebCenter Content and Email Checkin Team Member - John Sim (fueling his hacking mind)

WebCenter Content and Email Checkin Team Member – John Sim (fueling his hacking mind)

The hacking commenced at 3 PM today and will continue until 4 PM on Saturday, April 16th. Each team will then present their developed integration/component, and the other Fishbowl team members will vote on their favorite finished product. Check back on this blog next week to see who won.

Happy hacking!


Fishbowl Solutions Hackathon 2016 T-shirt



The post Hackathon weekend at Fishbowl Solutions – Google Vision, Slack, and Email Integrations with Oracle WebCenter appeared first on Fishbowl Solutions' C4 Blog.

Categories: Fusion Middleware, Other

Taking IBM Bluemix OpenWhisk for a Test Drive

Pas Apicella - Mon, 2016-04-11 05:27

OpenWhisk is a new event-driven platform that lets developers quickly and easily build feature-rich apps that automatically trigger responses to events. To read more about it view the link below. In this simple example we will explore it it's use from IBM Bluemix by returning Todays date.



1. Login to Bluemix using http://bluemix.net

2. Click on "Try OpenWhisk" as shown below

3. Once logged in to the new Bluemix Console you should see a screen as follows

At this point we can only use OpenWhisk from the command line

4. Click on "Configure CLI" button to install it

5. Once installed you can verify it's installed as follows

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk/actions$ wsk --help
usage: wsk [-h] [-v] [--apihost hostname] [--apiversion version]

OpenWhisk is a distributed compute service to add event-driven logic to your

optional arguments:
  -h, --help            show this help message and exit
  -v, --verbose         verbose output
  --apihost hostname    whisk API host
  --apiversion version  whisk API version

available commands:
    action              work with actions
    activation          work with activations
    namespace           work with namespaces
    package             work with packages
    rule                work with rules
    trigger             work with triggers
    sdk                 work with the SDK
    property            work with whisk properties
    list                list all triggers, actions, and rules in the registry

Learn more at https://developer.ibm.com/openwhisk fork on GitHub
https://github.com/openwhisk. All trademarks are the property of their
respective owners.

6. Now lets Set your OpenWhisk Namespace and Authorization Key. They are provided when you are taken to the install CLI for OpenWhisk, I simply create a script for this as follows

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk$ cat set-namespace-key
wsk property set --auth your-rather-long-key --namespace "pasapi@au1.ibm.com_dev"

Once run you get output as follows

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk$ ./set-namespace-key
ok: whisk auth set
ok: namespace set to pasapi@au1.ibm.com_dev

7.  Now create an OpenWhisk JavaScript function as shown below


 * Todays Date as an OpenWhisk action.
function main(params) {
    var currentTime = new Date();
    return {payload:  'Todays date is, ' + currentTime + '!'};

8. Create the OpenWhisk action as shown below

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk/actions$ wsk action create todaysdate todaysdate.js
ok: created action todaysdate

9. Invoke the action as shown below

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk/actions$  wsk action invoke todaysdate --blocking --result
    "payload": "Todays date is, Mon Apr 11 2016 10:14:56 GMT+0000 (UTC)!"

10. Invoke it again this displaying the full Response Object as shown below

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk/actions$  wsk action invoke todaysdate --blocking
ok: invoked todaysdate with id dbb447b65b06433a8b511187011f5715
    "result": {
        "payload": "Todays date is, Mon Apr 11 2016 10:19:07 GMT+0000 (UTC)!"
    "status": "success",
    "success": true

11. We can view our current actions using a command as follows, you can see we have added the "todaysdate" function

pasapicella@pas-macbook-pro:~/ibm/bluemix/openwhisk/actions$ wsk list
entities in namespace: pasapi@au1.ibm.com_dev
/pasapi@au1.ibm.com_dev/todaysdate                            private
/pasapi@au1.ibm.com_dev/hello                                     private

12. Now lets return to the Bluemix Web Console and click on "Inspect activity metrics and logs"
Here you can view what you have invoked

There is clearly more to OpenWhisk then just this BUT for more information the IBM Bluemix docs have some more demos to try out.

Categories: Fusion Middleware

Tomcat Runtime added to Web Console of IBM Bluemix

Pas Apicella - Thu, 2016-04-07 01:05
I almost always use the tomcat buildpack within IBM Bluemix for my Java based applications. By default IBM bluemix will use the IBM Liberty buildpack for java apps unless you specify otherwise. The buildpacks on Bluemix can be viewed using "cf buildpacks" and the tomcat buildpack is referred to as "java_buildpack"

So to use the tomcat buildpack in a manifest.yml you would target it as follows

- name: pas-javaapp
  memory: 512M
  instances: 1
  host: pas-javaapp
  domain: mybluemix.net
  path: ./passapp.war
  buildpack: java_buildpack

Now the Web Console catalog for "Runtimes" shows Tomcat for those creating an application from the Console itself. This was done for those who wish to use Tomcat on Bluemix can cleary see it's an option as per the screen shot below and don't have to start with the Liberty Buildpack if they don't wish to do so.

Categories: Fusion Middleware

A Designer’s Introduction to Oracle JET

I’m thrilled to be presenting at Collaborate 2016 with my colleague John Sim, on the recently open-sourced Oracle JET! We front-end developers had been seeking a better UI/UX solution from Oracle for quite some time, and they have delivered in a big way.


Oracle JavaScript Extension Toolkit (JET) is a powerful and intuitive framework that provides a modular toolkit for front-end developers. Rather than re-inventing the wheel, Oracle JET integrates tried and tested open-source frameworks and libraries like jQuery, KnockoutJS, and RequireJS with JET-specific pre-built UI components. Oracle JET is a flexible client-side framework that can integrate with a variety of back-end services. The combination makes for speedy assembly of client-side applications that integrate with Oracle products and services, especially Oracle Cloud services.


While Java may be the leading language in the industry, JavaScript has quickly gained popularity, especially for developing client-side user interactions. JET was initially built for Oracle in-house use, but Oracle customers and partners continued to ask for JavaScript-based UI development that could interact with existing Oracle platforms. JET provides the capabilities and flexibility of JS UI development, while complying with Oracle standards (internationalization and accessibility, for example) for product delivery.

Part of the beauty of JET, is in its modularity. It allows developers to use as much or as little as they need for a particular project. In addition, different libraries can be incorporated. As JS libraries evolve, and new frameworks are developed, the idea is that they can be incorporated, as well. Oracle JET’s flexibility ensures that it can change with the JS development world.

Our session is targeted at front-end developers looking to leverage their Javascript, CSS3, and HTML5 front- end design skills to create modular single page applications with JET. We’ll include an overview of the JET framework, and discuss the features and benefits along with a quick comparison with ADF (Application Development Framework). We will walk through and explain JET’s integrated open source libraries and frameworks, and then take developers through the creation of a simple JET application using Oracle DoCS REST API.

Please join us at 10:30AM on April 11 in Jasmine D for a dive into this flexible, open-source(!) and exciting new JS framework, and please come see all of the Fishbowl Solutions gang at Booth #1028!

The post A Designer’s Introduction to Oracle JET appeared first on Fishbowl Solutions' C4 Blog.

Categories: Fusion Middleware, Other

IBM Bluemix NodeRed Demo using Twitter and Telstra SMS API

Pas Apicella - Mon, 2016-03-21 21:48
In this example I integrate Twitter Feed with Telstra SMS API to send an SMS based. It is based on the wrapper application which exposes the Telstra SMS API on Bluemix as per a previous Post.


It is assumed you have NodeRed NodeJS application running on Bluemix and are at the Editor as shown below.


1. Drag a "Social -> Twitter" node onto the editor
2. Double click on the Node and ensure you add your twitter credentials and authorize twitter to work with NodeRed itself. Also use a FOR TAG you wish to receive as part of the feed from twitter, in this demo it is "#telstrasmaapi-pas"

3. Once done it will look as follows

4. Drag a "Function -> HTTP Request" onto the editor
5. Double click on the HTTP Request item and add details as shown below.

Method = POST
URL = http://pas-telstrasmsapi.mybluemix.net/telstrasms?to=0411151350&body=tweet sent about telstra SMS API
Name = Any name of your choice

Note: Ensure URL is changed to the mobile number you wish to use and a BODY you wish to send as part of the TEXT.

6. Connect the twitter node to the HTTP Request node as shown below.

7. Click the "Deploy" button
8. Now log into your Twitter account and send a Tweet using the TAG you identified above as shown below. You must use the TAG name you said your looking for in this case "#telstrasmaapi-pas"

9. It should then send an SMS to the identified mobile number you used (Australia Mobiles Only) as shown below.

More Information

For more information on NodeRed use the link below.


Categories: Fusion Middleware

Something Amiss

Greg Pavlik - Thu, 2016-03-17 00:02
Looks like this curious non-review of the novel Laurus seems to have been referring to "Brahmins" as "Brahman" - I suppose republished to correct the mistake:
​Russian Brahman by Alan Jacobs | Articles | First Things
First Things
Russian Brahman. by Alan Jacobs April 2016. Laurus by eugene vodolazkin translated by lisa hayden oneworld, 384 pages, $24.99. Eugene Vodolazkin's ...
​Russian Brahmin by Alan Jacobs | Articles | First Things
First Things
Russian Brahmin. by Alan Jacobs April 2016. Laurus by eugene vodolazkin translated by lisa hayden oneworld, 384 pages, $24.99. Eugene Vodolazkin's ...

Whatever his grasp of Hindu concepts, it's obvious Jacobs knows little to nothing about the tradition of Russian yurodivy, which makes this review overall kind of silly at best. Interested readers can refer to the hagiographies of Xenia of Petersburg or Feofil of the Kiev Caves Lavra to become acquainted with some of the conceptual background to the novel, both published by the monastery press in Jordanville, NY in English. As a complement the Pavel Lungin movie Ostrov is worth watching carefully - the film is based partly on Feofil, though like the life of St Xenia, it explores the theme of vicarious repentance. (It was not until the third time I saw the film that I fully grasped it - the visuals are stunning and in many respects a distraction.)

All of that aside, what continues to trouble me in general is the fact that most of the reviews of Laurus that I've seen have been oriented toward theological critiques - endorsements or arguments revolving around the reviewer's reading of what the author might want us to think about religion. And yet it is obvious that Vodolazkin did not write a religious apologetic (Jacobs invokes Karamazov, which is simultaneously a religious argument and a humanistic work - but Laurus is anything but the former). Laurus deserves a review as a work of notable - even great - world literature: which is to say first and foremost an exploration of what Vodolazkin is attempting to accomplish as a writer and what that has produced as a work of literature. The lack of serious analysis is particularly puzzling given the devices Vodolazkin uses to deal with language, identity, personality, relationship, and - yes - time. We could do with a few less sermons and a bit more thought.

Fishbowl Solutions at Collaborate 2016: Demos and Discussions on Oracle JET, ADF, Documents Cloud Service, Controlled Document Management and Portals

Fishbowl Solutions is looking forward to Collaborate 2016. We have another full list of activities planned, and we are always excited to meet with customers and discuss their initiatives around enterprise content management and portals, the cloud, as well as front-end user design and experience. With the release of Oracle WebCenter 12c back in October, customers are also eager to understand more of what the new version has to offer. Fortunately for WebCenter customers attending Collaborate, Fishbowl Solutions will be covering all these topics across the 5 presentations we will be giving, as well as one-on-discussions in our booth – #1028.

We are also privileged to be joined by two WebCenter customers who will give presentations on their WebCenter use cases. The first customer, ICON plc (www.iconplc.com/) based in Dublin, Ireland, will discuss the process of improving the front-end experience of the WebCenter-based portal they use to manage the clinical trials process.

The second customer is Rosendin Electric (www.rosendin.com) based in San Jose, CA, and they will share how they implemented Fishbowl’s ControlCenter solution to automate the contract management process within WebCenter.

The best part and biggest benefit of attending Collaborate is hearing stories from actual customers, like ICON and Rosendin. Collaborate is truly a user group conference, and hearing case studies on WebCenter deployments, enhancements, integrations, etc., are invaluable for other customers looking to do the same or similar. Less marketing speak and sales pitches, and more learning. As you plan your schedule for Collaborate, look for Session Types denoted as Case Studies.

Here is a preview of what Fishbowl currently has planned for Collaborate 2016.

Booth: 1028

Demos of our WebCenter Portal Solution Accelerator, User Experience (art of the possible) demos of portal and websites, and ControlCenter (controlled document management for WebCenter).

Presentations: 5

  • Monday, April 11, 10:30-11:30 AM:
    A Designer’s Introduction to the Oracle JET Framework

    This session is targeted at front-end developers looking to leverage their front-end design skills to create Modular Single Page applications with Oracle’s new JavaScript Extension Toolkit (JET) framework. The presentation will include an overview of the JET framework and discussion around the features and benefits, along with a quick comparison with Application Development Framework (ADF). Sim and Beatty will walk through and explain JET’s integrated open source libraries and frameworks, and then take developers through the creation of a simple, JET-integrated cloud application.

  • Monday, April 11, 4:30-5:30 PM:
    Integrating Oracle JET With ADF to Create a Modern and Engaging User Experience

    In this session you will learn about the pros and cons of Oracle’s new JET framework and ADF and how you can combine them to create a modern development experience writing Modular Single Page Applications. Sim and Weaver will discuss how front-end designers can create modern, platform agnostic extendable interfaces with JET, and how developers can create ADF integrations and extendable services with the back-end to serve up small data snippets (JSON).

  • Tuesday, April 12, 10:45-11:45 AM:
    Developing Hybrid Solutions for the Oracle Documents Cloud Service (DoCS)

    This session will provide an overview of Oracle’s Documents Cloud Service (DoCS), including its interface, security model, and how to embed the DoCS UI and integrate with the REST API and Applink Resource to create seamless hybrid off- and on-premise applications. As part of the lecture, Sim will provide live examples and code walkthroughs, as well as talk about hybrid application development and the best times to use the Applink Resource vs the REST API with Oracle’s new Oracle JET framework for developing cloud apps. The presentation will conclude with an overview of an integration that Fishbowl has created to support Oracle DoCs.

  • Tuesday, April 12, 4:45-5:45 PM
    ICON Enhances Its WebCenter Portal Design by Keeping the User in Mind

    ICON Clinical Research Limited is a global provider of outsourced development services to the pharmaceutical, biotechnology, and medical device industries. They specialize in the development, management, and analysis of programs that support clinical development. ICON implemented Oracle WebCenter as the platform for its ICONIK portal, which will be used by the clinical trials team to manage, maintain, and share content created during the trials process. Come to this session to hear how ICON and Fishbowl Solutions leveraged next generation, best practice portal design concepts and technologies to provide a high-end and rich user experience to end users. Learn how ICON leverages WebCenter Portal and Content to surface personalized study documents, quickly manage content, and collaborate with other team members, whether on a desktop or on the go through a mobile device. We will also discuss how ICON has streamlined their business to solve problems that contributed to delays in the clinical trials process, impeding ICON’s customers from bringing products to market.

  • Wednesday, April 13, 9:15-10:15 AM:
    Rosendin Electric Pairs a Modern User Experience with WebCenter Content to Automate Contract Management

    Rosendin Electric is the top-ranked private electrical contractor in the nation whose work spans preconstruction, prefabrication, building information modeling, and renewable energy. Join us to hear Rosendin describe how they leveraged Oracle WebCenter and Fishbowl Solutions’ ControlCenter to automate and improve their contract management process. Rosendin’s new contract management system provides an intuitive, mobile-enabled interface and dashboard view for their contracts team that shows working, pending, and executed contracts. This dashboard is specific for each user, enabling them to quickly take action not only on contracts, but also on associated documents such as non-disclosure agreements and corporate governance documentation. Come see how WebCenter Content has streamlined Rosendin’s contract management process, making it much more efficient while ensuring the lifecycle of contracts and related documents can be easily tracked, viewed, and archived within one enterprise repository.

We hope to see you at Collaborate 2016!

The post Fishbowl Solutions at Collaborate 2016: Demos and Discussions on Oracle JET, ADF, Documents Cloud Service, Controlled Document Management and Portals appeared first on Fishbowl Solutions' C4 Blog.

Categories: Fusion Middleware, Other

A Few of My Favorite Things for Ultimate Productivity with Oracle WebCenter

As an Oracle WebCenter consultant at Fishbowl Solutions, I have a number of tools that I use that keep me happy and productive. Whether or not you are a software developer, these tools can do the same for you and your business.




Unless you’ve been hibernating for the last year or so, you’ve probably heard of Slack. Haven’t adopted it for your business yet? Here’s why you should.

Slack facilitates contextual, transparent and efficient communication for teams. Slack helps organize your communications into “channels.” Working on a project with Fishbowl Solutions on a WebCenter project? Create a Slack channel and centralize your communications. Quickly share files with the entire team, and “Slackers” can give instant feedback. On the go? Slack goes with you via mobile, of course. Slack provides direct messaging and private channels, too.

Even better, Slack lets you integrate dozens of apps, so that you can centralize all of the services you and your team use. Send calendar reminders and events, search for documents, even start a Skype call. Slack is team communication for the 21st century (with custom emojis!).


Twitter and Evernote


Twitter and Evernote are my number one/two combo punch for staying on top of all things development. Twitter allows me to keep up to date with the latest news and trends in the web development world. I can peruse dozens of articles every day with information I want to store for later use. I save links to the best articles in my Evernote account, which I have organized into different notebooks for various topics. For example, I’m working on a presentation for Collaborate 16 on Oracle JET, Oracle’s new front-end JavaScript framework. Anything interesting I see on Twitter re: Oracle JET goes right into my Evernote notebook. It makes keeping track of news and information a breeze.




Trello is the application for list-making over-achievers (like me). I organize my to-dos into different “boards”, depending on the project. I have a different board for each project I’m working on at Fishbowl. As I think of something I need to do, I can quickly add it to the appropriate to-do column. When I’m busy with a task, I put it in the “doing” column, and then slide it on over to “done” when finished. I can keep up with my task flow, it’s motivating, visually appealing, and goes with me where I go. Trello also allows me to share tables with others for easy collaboration. Oh, and did I mention I can integrate Trello with Slack (insert custom Slack emoji here)?



Toggl is a fantastic little desktop timer tool my colleague Nate Yates introduced to me. We consultants at Fishbowl Solutions need to keep very accurate timing of the hours we spend on different projects. Toggl allows me to input my different projects, and then just click the appropriate button when I start working on it. It keeps track of my time for the week on each project. It makes keeping track of my time simple, so that I can focus most of my time on creating responsive single-page applications for Fishbowl Solutions customers.



The post A Few of My Favorite Things for Ultimate Productivity with Oracle WebCenter appeared first on Fishbowl Solutions' C4 Blog.

Categories: Fusion Middleware, Other

Bluemix CLI Installation and Use on Bluemix PUBLIC

Pas Apicella - Thu, 2016-02-18 04:53
We recently announced a seperate CLI for Bluemix known as "Bluemix CLI". You can find out more about it at the following link


The Bluemix command line interface (CLI) provides a set of commands that are grouped by namespace for users to interact with Bluemix. Some Bluemix CLI commands, which are called bx commands, are wrappers of existing cf commands, and others are unique for Bluemix. The information that follows lists all commands that are supported by Bluemix CLI and includes their names, options, usage, prerequisites, descriptions, and examples.

Download it from Here


The following shows how to use it once you installed it for you operating System.

1. Target End Point

pasapicella@pas-macbook-pro:~$ bluemix api https://api.ng.bluemix.net
Invoke 'cf api https://api.ng.bluemix.net'...

Setting api endpoint to https://api.ng.bluemix.net...

API endpoint:   https://api.ng.bluemix.net (API version: 2.40.0)
Not logged in. Use 'bluemix login' to log in.

2. Login as shown below

pasapicella@pas-macbook-pro:~$ bluemix login -u pasapi@au1.ibm.com -p ****** -o pasapi@au1.ibm.com -s dev
Invoke 'cf login -u pasapi@au1.ibm.com -p ****** -o pasapi@au1.ibm.com -s dev'...

API endpoint: https://api.ng.bluemix.net

Targeted org pasapi@au1.ibm.com

Targeted space dev

API endpoint:   https://api.ng.bluemix.net (API version: 2.40.0)
User:           pasapi@au1.ibm.com
Org:            pasapi@au1.ibm.com
Space:          dev

3. Test the "bluemix info" call.

pasapicella@pas-macbook-pro:~$ bluemix info
Listing Bluemix info...

build:                      221004
routing_endpoint:           https://api.ng.bluemix.net/routing
console_endpoint:           https://mccp.ng.bluemix.net
region:                     us-south
app_ssh_endpoint:           ssh.ng.bluemix.net:2222
vms_endpoint:               https://mccp.ng.bluemix.net
token_endpoint:             https://mccp.ng.bluemix.net/uaa
containers_endpoint:        https://mccp.ng.bluemix.net
version:                    2
description:                IBM Bluemix
user:                       b6c020b4-e11a-4630-a6a2-3f20fcec7f90
app_ssh_oauth_client:       ssh-proxy
logging_endpoint:           wss://loggregator.ng.bluemix.net:443
doppler_logging_endpoint:   wss://doppler.ng.bluemix.net:4443
authorization_endpoint:     https://mccp.ng.bluemix.net/login
api_version:                2.40.0
name:                       Bluemix
support:                    http://ibm.com

And my favorite which is the "bluemix list" command.

pasapicella@pas-macbook-pro:~$ bluemix list
Getting CF applications in org 'pasapi@au1.ibm.com' / space 'dev' as pasapi@au1.ibm.com...
Name                        Type             State     Instances   Memory   Disk   URLs
bluemix-apples-springboot   CF Application   STARTED   1/1         512M     1G     bluemix-apples-protozoological-yabby.mybluemix.net
containerbridge             CF Application   STOPPED   0/1         64M      1M
pas-bmspringboot-demo       CF Application   STARTED   1/1         512M     1G     pas-bmspringboot-demo.mybluemix.net
pas-dotnet-helloworld       CF Application   STARTED   1/1         256M     1G     pas-dotnet-helloworld.mybluemix.net
pas-mjalbums                CF Application   STARTED   1/1         512M     1G     pas-mjalbums.mybluemix.net
pas-mobile-web              CF Application   STARTED   1/1         512M     1G     pas-mobile-web.mybluemix.net
pas-mongodb-local           CF Application   STARTED   1/1         450M     1G     pas-mongodb-local.mybluemix.net
pas-mysql-local             CF Application   STARTED   1/1         450M     1G     pas-mysql-local.mybluemix.net
pas-postgresql-local        CF Application   STARTED   1/1         450M     1G     pas-postgresql-local.mybluemix.net
pas-sb-elastic              CF Application   STARTED   1/1         450M     1G     pas-sb-elastic.mybluemix.net
pas-SpringBootJARDemo       CF Application   STARTED   1/1         512M     1G     pas-SpringBootJARDemo.mybluemix.net
pas-tonynode                CF Application   STARTED   1/1         512M     1G     pas-tonynode.mybluemix.net
springboot-swagger-rest     CF Application   STARTED   1/1         512M     1G     apples-sacroiliac-subfacies.mybluemix.net

Getting services in org 'pasapi@au1.ibm.com' / space 'dev' as pasapi@au1.ibm.com...
Name                              Type               Service           Plan               Bound CF Apps                                                            Last Operation
API Management-wv                 Service Instance   API Management    APImStandardPlan
BlazeMeter-92                     Service Instance   blazemeter        free-tier
cleardb-mysql                     Service Instance   cleardb           spark              pas-SpringBootJARDemo
Cloudant-NoSQL-DB-mel-training    Service Instance   cloudantNoSQLDB   Shared
dev_elephantsql                   Service Instance   elephantsql       turtle             bluemix-apples-springboot, pas-postgresql-local, pas-SpringBootJARDemo
jhipster-postgresql               Service Instance   elephantsql       turtle
pas-mongodb                       Service Instance   mongodb           100                pas-mongodb-local
pas-mongodb-lab                   Service Instance   mongolab          sandbox
pas-mysql                         Service Instance   cleardb           spark              containerbridge, pas-mjalbums, pas-mysql-local
pas-telstrademo-cloudantNoSQLDB   Service Instance   cloudantNoSQLDB   Shared
todo-mongo-db                     Service Instance   mongolab          sandbox
Twilio-7b                         Service Instance

Getting containers in org 'pasapi@au1.ibm.com' / space 'dev' as pasapi@au1.ibm.com...
No containers were found.

Getting container groups in org 'pasapi@au1.ibm.com' / space 'dev' as pasapi@au1.ibm.com...
Name                  Type              State             Instances   Memory   URLs
pas-etherpad1         Container Group   RESIZE_FAILED     0/1         256M     pas-etherpad1.mybluemix.net
pas-sb-container      Container Group   UPDATE_COMPLETE   1/1         512M     pas-sb-container.mybluemix.net
pas-mysql-container   Container Group   CREATE_COMPLETE   1/1         512M

Getting VM groups in org 'pasapi@au1.ibm.com' / space 'dev' as pasapi@au1.ibm.com...
No VM groups were found.
Categories: Fusion Middleware

Invoking the Billing API for Bluemix Public Organizations

Pas Apicella - Tue, 2016-02-09 17:09
The ability to view usage data from a billing perspective on IBM Bluemix Public is available as a REST based API. To use it follow the steps below.

In order to use the API you have to have the Billing Manager Role or be the Account Owner of the organization as shown below.


1. Log into the PUBLIC Bluemix region as shown below

pasapicella@Pas-MacBook-Pro:~$ cf login -u pasapi@au1.ibm.com -p ***** -o pasapi@au1.ibm.com -s dev
API endpoint: https://api.ng.bluemix.net

Targeted org pasapi@au1.ibm.com

Targeted space dev

API endpoint:   https://api.ng.bluemix.net (API version: 2.40.0)
User:           pasapi@au1.ibm.com
Org:            pasapi@au1.ibm.com
Space:          dev

2. List all your Organizations as shown below

pasapicella@Pas-MacBook-Pro:~$ cf orgs
Getting orgs as pasapi@au1.ibm.com...

NAB Experimentation

3. Determine the GUID of the Org you wnat to get metering usage from

pasapicella@Pas-MacBook-Pro:~$ cf org pasapi@au1.ibm.com --guid

4. Determine the region name for the PUBLIC instance your connected to as follows

pasapicella@Pas-MacBook-Pro:~$ curl http://mccp.ng.bluemix.net/info
  "name": "Bluemix",
  "build": "221004",
  "support": "http://ibm.com",
  "version": 2,
  "description": "IBM Bluemix",
  "authorization_endpoint": "https://mccp.ng.bluemix.net/login",
  "token_endpoint": "https://mccp.ng.bluemix.net/uaa",
  "min_cli_version": null,
  "min_recommended_cli_version": null,
  "api_version": "2.40.0",
  "app_ssh_endpoint": "ssh.ng.bluemix.net:2222",
  "app_ssh_host_key_fingerprint": null,
  "app_ssh_oauth_client": "ssh-proxy",
  "routing_endpoint": "https://api.ng.bluemix.net/routing",
  "logging_endpoint": "wss://loggregator.ng.bluemix.net:443",
  "doppler_logging_endpoint": "wss://doppler.ng.bluemix.net:4443",
  "console_endpoint": "https://mccp.ng.bluemix.net/console",
  "region": "us-south"

5. Determine the OAUTH token for your connected session as follows

pasapicella@Pas-MacBook-Pro:~$ cf oauth-token
Getting OAuth token...

bearer eyJhbGciOiJIUzI1NiJ9.eyJqdGkiOiI0ODAzOWM1My0yODZhLTQ5Y2YtYWIzYi0yNGVhZTY


At this point we are ready to invoke the Billing/Metering API. The format is as follows

Bluemix Endpoint:


  1. ORG_ID : Account GUID
  2. YYYY-MM: Year and month for which usage is required
Format as follows:

curl -v -X GET -H "Authorization: bearer {oauth-token}" "https://rated-usage.ng.bluemix.net/v2/metering/organizations/us-south:e270a605-978e-45fc-9507-00a50dec2469/usage/2016-02" | python -m json.tool
6. To invoke using curl we should do it as follows


pasapicella@Pas-MacBook-Pro:~$ curl -v -X GET -H "Authorization: bearer {oauth-token}" "https://rated-usage.ng.bluemix.net/v2/metering/organizations/us-south:e270a605-978e-45fc-9507-00a50dec2469/usage/2016-02" | python -m json.tool
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
  0     0    0     0    0     0      0      0 --:--:-- --:--:-- --:--:--     0*   Trying
* Connected to rated-usage.ng.bluemix.net ( port 443 (#0)
* TLS 1.2 connection using TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384
* Server certificate: *.ng.bluemix.net
* Server certificate: DigiCert SHA2 Secure Server CA
* Server certificate: DigiCert Global Root CA
  0     0    0     0    0     0      0      0 --:--:--  0:00:01 --:--:--     0> GET /v2/metering/organizations/us-south:e270a605-978e-45fc-9507-00a50dec2469/usage/2016-02 HTTP/1.1
> Host: rated-usage.ng.bluemix.net
> User-Agent: curl/7.43.0
> Accept: */*
> Authorization: bearer eyJhbGciOiJIUzI1NiJ9.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.EUEIXZ-XgxQbvTQnSgrToODHbNmKvhx0PtAp9CaiPTk
  0     0    0     0    0     0      0      0 --:--:--  0:00:04 --:--:--     0< HTTP/1.1 200 OK
< X-Backside-Transport: OK OK
< Connection: Keep-Alive
< Transfer-Encoding: chunked
< Content-Type: application/json; charset=utf-8
< Date: Tue, 09 Feb 2016 22:54:44 GMT
< Etag: W/"3bcc-JgmFioUYI4v46tUXnGY1SQ"
< Vary: Accept-Encoding
< X-Cf-Requestid: 7b5cea8c-1a24-4114-44b2-a45e5d6e6f40
< X-Heap-Used: 136304240
< X-Instance-Id: 657c5e04638a49788a1053e7bb4e22ff
< X-Instance-Index: 5
< X-Node-Version: v0.10.41
< X-Powered-By: Express
< X-Process-Id: 93
< X-Response-Time: 3374.537ms
< X-Uptime: 16055
< X-Client-IP:
< X-Global-Transaction-ID: 750960253
{ [4055 bytes data]
100 15308    0 15308    0     0   3019      0 --:--:--  0:00:05 --:--:--  3967
* Connection #0 to host rated-usage.ng.bluemix.net left intact
    "organizations": [
            "billable_usage": {
                "spaces": []
            "currency_code": "AUD",
            "id": "e270a605-978e-45fc-9507-00a50dec2469",
            "name": "pasapi@au1.ibm.com",
            "non_billable_usage": {
                "spaces": [
                        "applications": [
                                "id": "121ccef0-2417-49c4-9f8f-47958b6d819d",
                                "name": "pas-bmspringboot-demo",
                                "usage": [
                                        "buildpack": "0154f971-ae72-4882-9695-bda6e31310b7",
                                        "cost": 8.531996000805556,
                                        "quantity": 107.45586902777778,
                                        "runtime": {
                                            "id": "0154f971-ae72-4882-9695-bda6e31310b7",
                                            "name": "liberty-for-java_v2_1-20151006-0912"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "2d7dfb5f-0900-4c4a-a936-edaf3b7febb8",
                                "name": "pas-tonynode",
                                "usage": [
                                        "buildpack": "f0bff590-8b49-4c7d-bc4a-3ff24adcd411",
                                        "cost": 8.531996000805556,
                                        "quantity": 107.45586902777778,
                                        "runtime": {
                                            "id": "f0bff590-8b49-4c7d-bc4a-3ff24adcd411",
                                            "name": "sdk-for-nodejs_v2_8-20151209-1403"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "3a962319-e7c4-456f-a2a4-b1f356a5d142",
                                "name": "pas-dotnet-helloworld",
                                "usage": [
                                        "buildpack": "0a566654-d250-463e-b413-67782482e903",
                                        "cost": 4.265998000402778,
                                        "quantity": 53.72793451388889,
                                        "runtime": {
                                            "id": "0a566654-d250-463e-b413-67782482e903",
                                            "name": "aspnet5-experimental"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "54629864-0e43-488f-bfca-3f9c9d806de6",
                                "name": "pas-mysql-local",
                                "usage": [
                                        "buildpack": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                        "cost": 7.498824610083008,
                                        "quantity": 94.44363488769531,
                                        "runtime": {
                                            "id": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                            "name": "java_buildpack"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "59f15702-1c42-444b-a1fb-94fbaf6cb27a",
                                "name": "pas-mobile-web",
                                "usage": [
                                        "buildpack": "0154f971-ae72-4882-9695-bda6e31310b7",
                                        "cost": 8.531996000805556,
                                        "quantity": 107.45586902777778,
                                        "runtime": {
                                            "id": "0154f971-ae72-4882-9695-bda6e31310b7",
                                            "name": "liberty-for-java_v2_1-20151006-0912"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "926900dd-ccd7-4442-8f58-413df2bc0237",
                                "name": "pas-mongodb-local",
                                "usage": [
                                        "buildpack": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                        "cost": 7.498824610083008,
                                        "quantity": 94.44363488769531,
                                        "runtime": {
                                            "id": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                            "name": "java_buildpack"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "ab5a3278-a1c1-44f6-9113-713a4d800131",
                                "name": "bluemix-apples-springboot",
                                "usage": [
                                        "buildpack": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                        "cost": 8.531996000805556,
                                        "quantity": 107.45586902777778,
                                        "runtime": {
                                            "id": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                            "name": "java_buildpack"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "b448fd3a-5350-47d2-820d-7f739a057f22",
                                "name": "pas-SpringBootJARDemo",
                                "usage": [
                                        "buildpack": "eb0b11e9-8982-4b93-adcb-7350d0bf2ae4",
                                        "cost": 8.531996000805556,
                                        "quantity": 107.45586902777778,
                                        "runtime": {
                                            "id": "eb0b11e9-8982-4b93-adcb-7350d0bf2ae4",
                                            "name": "liberty-for-java_v2_3-20151208-1311"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"
                                "id": "b7d3d442-5546-41b4-b5c0-4ef737734e7b",
                                "name": "pas-sb-elastic",
                                "usage": [
                                        "buildpack": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                        "cost": 7.498824610083008,
                                        "quantity": 94.44363488769531,
                                        "runtime": {
                                            "id": "dac36860-94be-495a-96f5-d81d79c2ef3f",
                                            "name": "java_buildpack"
                                        "unit": "GB-HOURS",
                                        "unitId": "GB_HOURS_PER_MONTH"

Categories: Fusion Middleware

Adding community based Plugins to the CF CLI Tool

Pas Apicella - Tue, 2016-01-26 17:02
I needed a community based plugin recently and this is how you would add it to your CF CLI interface.

1. Add Community based REPO as shown below

$ cf add-plugin-repo community http://plugins.cfapps.io/

2. Check available plugins from REPO added above

pasapicella@Pas-MacBook-Pro:~/ibm$ cf repo-plugins community
Getting plugins from all repositories ...

Repository: CF-Community
name                      version   description
Download Droplet          1.0.0     Download droplets to your local machine
Firehose Plugin           0.8.0     This plugin allows you to connect to the firehose (CF admins only)
doctor                    1.0.1     doctor scans your deployed applications, routes and services for anomalies and reports any issues found. (CLI v6.7.0+)
manifest-generator        1.0.0     Help you to generate a manifest from 0 (CLI v6.7.0+)
Diego-Enabler             1.0.1     Enable/Disable Diego support for an app (CLI v6.13.0+)

3. Install plugin as shown below

pasapicella@Pas-MacBook-Pro:~/ibm/$ cf install-plugin "Live Stats" -r community

**Attention: Plugins are binaries written by potentially untrusted authors. Install and use plugins at your own risk.**

Do you want to install the plugin Live Stats? (y or n)> y
Looking up 'Live Stats' from repository 'community'
7874156 bytes downloaded...
Installing plugin /var/folders/rj/5r89y5nd6pd4c9hwkbvdp_1w0000gn/T/cf-plugin-stats...
Plugin Live Stats v0.0.0 successfully installed.

4. View plugin commands

pasapicella@Pas-MacBook-Pro:~/ibm/$ cf plugins
Listing Installed Plugins...

Plugin Name       Version   Command Name                                           Command Help
IBM-Containers    0.8.788   ic                                                     IBM Containers plug-in

Live Stats        N/A       live-stats                                             Show browser based stats
active-deploy     0.1.22    active-deploy-service-info                             Reports version information about the CLI and Active Deploy service. It also reports the cloud back ends enabled by the Active Deploy service instance.

Categories: Fusion Middleware

ServletContextAware Controller class with Spring

Pas Apicella - Mon, 2016-01-25 03:55
I rarely need to save state within the Servlet Context via an application scope, but recently I did and here is what your controller class would look like to get access to the ServletConext with Spring. I was using Spring Boot 1.3.2.RELEASE.

In short you implement the "org.springframework.web.context.ServletContextAware" interface as shown below. In this example we retrieve an application scope attribute.
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.boot.json.JsonParser;
import org.springframework.boot.json.JsonParserFactory;
import org.springframework.stereotype.Controller;
import org.springframework.ui.Model;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.context.ServletContextAware;

import javax.servlet.ServletContext;
import java.util.ArrayList;
import java.util.List;
import java.util.Map;

public class CommentatorController implements ServletContextAware
private static final Logger log = LoggerFactory.getLogger(CommentatorController.class);
private static final JsonParser parser = JsonParserFactory.getJsonParser();

private ServletContext context;

public void setServletContext(ServletContext servletContext)
this.context = servletContext;

@RequestMapping(value="/", method = RequestMethod.GET)
public String listTeams (Model model)
String jsonString = (String) context.getAttribute("riderData");
List<Rider> riders = new ArrayList<>();

if (jsonString != null)
if (jsonString.trim().length() != 0)
Map<String, Object> jsonMap = parser.parseMap(jsonString);
List<Object> riderList = (List<Object>) jsonMap.get("Riders");

for (Object rider: riderList)
Map m = (Map) rider;
new Rider((String)m.get("RiderId"),

//log.info("Riders = " + riders.size());
model.addAttribute("ridercount", riders.size());
model.addAttribute("ridercount", 0);

model.addAttribute("riders", riders);

return "commentator";

Categories: Fusion Middleware


Greg Pavlik - Thu, 2015-12-24 09:24
Shadows flicker against the wall
within the cave it is perpetually night
(I find my vision gets dimmer with age
- when we are alleged to see more sharply -
in the low light of a single candle flame
it is getting much harder to read
year by year)
there is a form I barely am able to perceive.
I wonder if it is better here than the open air
where my eyes would surely be closed against the sun
where all forms find their origin in the one.



Greg Pavlik - Sun, 2015-12-20 23:11
Blown away to get my purple belt in Brazilian Jiu Jitsu from 10th Planet black belt Alex Canders.

IBM Containers running Spring Boot Applications with IBM Bluemix

Pas Apicella - Wed, 2015-12-02 16:56
There is now a new command line plugin for IBM containers on Bluemix so you can push and run docker images using CF CLI itself. The steps below show you how to set this up and I use a basic spring boot application as a docker image to test this out.


Take a note of the docker local host IP. In this example it was as follows, as I test my docker image on my laptop prior to pushing it to Bluemix.

-> docker is configured to use the default machine with IP

1. Install the latest CF command line, I used the following version.

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ cf --version
cf version 6.14.0+2654a47-2015-11-18


2. Install IBM Containers Cloud Foundry plug-in

pasapicella@pas-macbook-pro:~$ cf install-plugin https://static-ice.ng.bluemix.net/ibm-containers-mac

**Attention: Plugins are binaries written by potentially untrusted authors. Install and use plugins at your own risk.**

Do you want to install the plugin https://static-ice.ng.bluemix.net/ibm-containers-mac? (y or n)> y

Attempting to download binary file from internet address...
9314192 bytes downloaded...
Installing plugin /var/folders/rj/5r89y5nd6pd4c9hwkbvdp_1w0000gn/T/ibm-containers-mac...
Plugin IBM-Containers v0.8.788 successfully installed.

Note: Default plugin directory as follows


3. Login to IBM Containers

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS$ cf ic login
Client certificates are being retrieved from IBM Containers...
Client certificates are being stored in /Users/pasapicella/.ice/certs/...
Client certificates are being stored in /Users/pasapicella/.ice/certs/containers-api.ng.bluemix.net/0bcbcada-bd11-4372-b416-955dff3078a1...
Client certificates were retrieved.

Deleting old configuration file...
Checking local Docker configuration...

Authenticating with registry at host name registry.ng.bluemix.net
Your container was authenticated with the IBM Containers registry.
Your private Bluemix repository is URL: registry.ng.bluemix.net/apples

You can choose from two ways to use the Docker CLI with IBM Containers:

Option 1: This option allows you to use "cf ic" for managing containers on IBM Containers while still using the Docker CLI directly to manage your local Docker host.
    Use this Cloud Foundry IBM Containers plug-in without affecting the local Docker environment:

    Example Usage:
    cf ic ps
    cf ic images

Option 2: Use the Docker CLI directly. In this shell, override the local Docker environment to connect to IBM Containers by setting these variables. Copy and paste the following commands:
    Note: Only Docker commands followed by (Docker) are supported with this option.

     export DOCKER_HOST=tcp://containers-api.ng.bluemix.net:8443
     export DOCKER_CERT_PATH=/Users/pasapicella/.ice/certs/containers-api.ng.bluemix.net/0bcbcada-bd11-4372-b416-955dff3078a1
     export DOCKER_TLS_VERIFY=1

    Example Usage:
    docker ps
    docker images
4. View docker images

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS$ cf ic images
REPOSITORY                                        TAG                 IMAGE ID            CREATED             VIRTUAL SIZE
registry.ng.bluemix.net/ibm-mobilefirst-starter   latest              5996bb6e51a1        6 weeks ago         770.4 MB
registry.ng.bluemix.net/ibm-node-strong-pm        latest              ef21e9d1656c        8 weeks ago         528.7 MB
registry.ng.bluemix.net/ibmliberty                latest              2209a9732f35        8 weeks ago         492.8 MB
registry.ng.bluemix.net/ibmnode                   latest              8f962f6afc9a        8 weeks ago         429 MB
registry.ng.bluemix.net/apples/etherpad_bluemix   latest              131fd7a39dff        11 weeks ago        570 MB

5. Clone application to run as docker image

$ git clone https://github.com/spring-guides/gs-rest-service.git

6. Create a file called Dockerfile as follows in the "complete" directory

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ cat Dockerfile
FROM java:8
ADD target/gs-rest-service-0.1.0.jar app.jar
RUN bash -c 'touch /app.jar'
ENTRYPOINT ["java","-Djava.security.egd=file:/dev/./urandom","-jar","/app.jar"]

7. Package the demo

$ mvn package

8. Build docker image

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ docker build -t gs-rest-service .
Sending build context to Docker daemon 13.44 MB
Step 1 : FROM java:8
8: Pulling from library/java
1565e86129b8: Pull complete
a604b236bcde: Pull complete
5822f840e16b: Pull complete
276ac25b516c: Pull complete
5d32526c1c0e: Pull complete
0d61f7a71c59: Pull complete
16952eac0a64: Pull complete
2fb3388c8597: Pull complete
ca603b247c8e: Pull complete
1785f2bc7c99: Pull complete
40e61a6ae215: Pull complete
32f541968fe6: Pull complete
Digest: sha256:52a1b487ed34f5a76f88a336a740cdd3e7b4486e264a3e69ece7b96e76d9f1dd
Status: Downloaded newer image for java:8
 ---> 32f541968fe6
Step 2 : VOLUME /tmp
 ---> Running in 030f739777ac
 ---> 22bf0f9356a1
Removing intermediate container 030f739777ac
Step 3 : ADD target/gs-rest-service-0.1.0.jar app.jar
 ---> ac590c46b73b
Removing intermediate container 9790c39eb1f7
Step 4 : RUN bash -c 'touch /app.jar'
 ---> Running in e9350ddebb75
 ---> 697d245c6afb
Removing intermediate container e9350ddebb75
Step 5 : ENTRYPOINT java -Djava.security.egd=file:/dev/./urandom -jar /app.jar
 ---> Running in 42fc22473930
 ---> df853abfea57
Removing intermediate container 42fc22473930
Successfully built df853abfea57

9. Run locally

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ docker run --name gs-rest-service -p 80:8080 -d -t gs-rest-service

10. Test as follows

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers$ curl
{"id":1,"content":"Hello, World!"}

11. PUSH TO BLUEMIX AS follows

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ docker tag gs-rest-service registry.ng.bluemix.net/apples/gs-rest-service
pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ docker push registry.ng.bluemix.net/apples/gs-rest-service
The push refers to a repository [registry.ng.bluemix.net/apples/gs-rest-service] (len: 1)
Sending image list
Pushing repository registry.ng.bluemix.net/apples/gs-rest-service (1 tags)
Image 5822f840e16b already pushed, skipping
Image 276ac25b516c already pushed, skipping
Image 5d32526c1c0e already pushed, skipping
Image a604b236bcde already pushed, skipping
Image 1565e86129b8 already pushed, skipping
Image 0d61f7a71c59 already pushed, skipping
Image 2fb3388c8597 already pushed, skipping
Image 16952eac0a64 already pushed, skipping
Image ca603b247c8e already pushed, skipping
Image 1785f2bc7c99 already pushed, skipping
Image 40e61a6ae215 already pushed, skipping
Image 32f541968fe6 already pushed, skipping
22bf0f9356a1: Image successfully pushed
ac590c46b73b: Image successfully pushed
697d245c6afb: Image successfully pushed
df853abfea57: Image successfully pushed
Pushing tag for rev [df853abfea57] on {https://registry.ng.bluemix.net/v1/repositories/apples/gs-rest-service/tags/latest}

12. List all allocated IP

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ cf ic ip list
Number of allocated public IP addresses:  2

IpAddress        ContainerId

13. Create a container from the uploaded image

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ cf ic run -p 8080 --memory 512 --name pas-sb-container registry.ng.bluemix.net/apples/gs-rest-service:latest

14. Assign IP to container

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ cf ic ip bind pas-sb-container
The IP address was bound successfully.

15. Verify it's running

pasapicella@pas-macbook-pro:~/bluemix_apps/CONTAINERS/ibm-containers/gs-rest-service/complete$ cf ic ps -a
CONTAINER ID        IMAGE               COMMAND             CREATED             STATUS                  PORTS                          NAMES
3794802b-b0c                  ""                  4 minutes ago       Running 3 minutes ago>8080/tcp   pas-sb-container

16. Invoke as follows

$ curl

More Information

Plugin Reference ->


Installing cf ci plugin ->


Categories: Fusion Middleware

IBM Bluemix Secure Gateway Service with Oracle

Pas Apicella - Thu, 2015-11-19 22:47
I previously blogged about using the IBM Bluemix Secure Gateway Service as follows


I decided I would extend on this and Connect a Spring Boot Application to Oracle and consume Oracle data using the Secure Gateway Service.

The full demo is as follows


Categories: Fusion Middleware

IBM Bluemix Secure Gateway Service Step by Step Demo

Pas Apicella - Tue, 2015-11-17 21:15
I created this simple step by step guide on how to use the IBM Secure Gateway Service. Very simple demo which shows how easy it is to set this up and open a world of possibilities from on premise resources directly exposed via Bluemix whether it's PUBLIC or Dedicated/LOcal Instances


Categories: Fusion Middleware

IBM Bluemix Admin Console Command Line (CLI) Installation

Pas Apicella - Mon, 2015-11-09 20:32
The IBM Bluemix Dedicated/Local Administration Console also includes support for CLI to enable common management tasks to be performed using the Cloud Foundry Command Line by adding a plugin to enable support for it's commands.

Note: The Bluemix Admin CLI plugin requires version 6.11.2 or later.

Admin Console UI

Admin Console - Installing Command Line

The CLI to the admin console is installed as follows. The reference to this is found in your own Dedicated/Local install via a link as follows with "cli" appended to the Admin Console URL


pro:~$ cf add-plugin-repo BluemixAdmin https://opsconsole.mylocalinstance.bluemix.net/cli

https://opsconsole.mylocalinstance.bluemix.net/cli/list added as 'BluemixAdmin'

pasapicella@pas-macbook-pro:~$ cf install-plugin bluemix-admin-cli -r BluemixAdmin
Looking up 'bluemix-admin-cli' from repository 'BluemixAdmin'
8889440 bytes downloaded...
Installing plugin /var/folders/rj/5r89y5nd6pd4c9hwkbvdp_1w0000gn/T/bluemix-admin...
Plugin BluemixAdminCLI v0.0.1 successfully installed.
pasapicella@pas-macbook-pro:~$ cf plugins
Listing Installed Plugins...


Finally target admin API endpoint:

pasapicella@pas-macbook-pro:~$ cf baa https://opsconsole.mylocalinstance.bluemix.net
The API endpoint has been updated to 'https://opsconsole.mylocalinstance.bluemix.net'

At this point you can now run Admin Console commands as follows. To get help issue "cf {command} --help"
The current supported commands are as follows:
bluemix-admin-api, baa
bluemix-admin-add-user, baau
bluemix-admin-remove-user, baru
bluemix-admin-set-organization, baso
bluemix-admin-unset-organization, bauo
bluemix-admin-set-quota, basq
bluemix-admin-add-report, baar
bluemix-admin-delete-report, badr
bluemix-admin-retrieve-report, barr
bluemix-admin-enable-service-plan, baesp
bluemix-admin-disable-service-plan, badsp
bluemix-admin-add-service-plan-visibility, baaspv
bluemix-admin-remove-service-plan-visibility, barspv
bluemix-admin-edit-service-plan-visibilites, baespv
bluemix-admin-set-region-access, basra
bluemix-admin-create-organization, baco
bluemix-admin-delete-organization, bado
Categories: Fusion Middleware

Spring Security Demo with a Bootstrap Look and Feel

Pas Apicella - Sun, 2015-11-08 21:31
I decided to take the Spring Security demo at the following link , and add Bootstrap to it. In the end it's basically the same code and the Form Based Login will accept one user "pas/welcome1".


Here is the updated demo with Bootstrap added to the UI pages. You can deploy this to Bluemix using the "Deploy to Bluemix" directly from GitHub and it will as you to Sing into IBM devOps prior to deploying it directly into your Bluemix Environment.


Categories: Fusion Middleware


Subscribe to Oracle FAQ aggregator - Fusion Middleware
